Schneider Electric QOU1401042 Miniature Circuit Breaker 120/240V 40A
SKU:
QOU1401042
UPC:
785901585787
MPN:
Condition:
New
Range Of Product:
QOU
Warranty:
18 months
Electrical Connection:
slotted box lugs, line side || slotted box lugs, load side
Toxic Heavy Metal Free:
Yes
Circuit Breaker Application:
HACR rated
Circuit Breaker Type:
standard
Circularity Profile:
N/A
Product Certifications:
CSA || UL Listed || IEC
Product Or Component Type:
miniature circuit-breaker
Mercury Free:
Yes
Awg Gauge:
AWG 14...AWG 2 aluminium/copper
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Rohs Exemption Information:
Yes
Eu Rohs Directive:
Compliant with Exemptions
Mounting Mode:
unit mount
Depth:
2.95 in
Tightening Torque:
45-45 lbf.in (AWG 14...AWG 2)
Width:
1.5 in
Line Rated Current:
40 A
Height:
4.05 in
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle...
QOU unit mount miniature circuit breakers (cable-in/cable-out) are ideal for OEM applications. QOU breakers are one, two or three pole thermal magnetic circuit breakers which provide overcurrent...
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle...
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle...
