Schneider Electric QOU2201021 Miniature Circuit Breaker 120/240V 20A

(No reviews yet) Write a Review
SKU:
QOU2201021
UPC:
785901517917
Condition:
New
Product Or Component Type:
miniature circuit-breaker
Halogen Content Performance:
Halogen free product
Mercury Free:
Yes
Depth:
2.95 in
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
[Ue] Rated Operational Voltage:
120/240 V AC || 120 V AC || 48 V DC
Width:
2.25 in
Product Certifications:
CSA || IEC || UL Listed
Toxic Heavy Metal Free:
Yes
Circuit Breaker Application:
HACR rated
Eu Rohs Directive:
Compliant with Exemptions
Circularity Profile:
N/A
Circuit Breaker Type:
standard
Sustainable Offer Status:
Green Premium product
Line Rated Current:
20 A
Height:
4.05 in
Tightening Torque:
45-45 lbf.in (AWG 14...AWG 2)
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Awg Gauge:
AWG 14...AWG 2 aluminium/copper
Rohs Exemption Information:
Yes
Electrical Connection:
slotted box lugs, line side || slotted box lugs, load side
Range Of Product:
QOU
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Warranty:
18 months
Mounting Mode:
unit mount
Brochure:
View
Catalog:
View
Datasheet:
View
$276.00

Description

QOU unit mount miniature circuit breakers (cable-in/cable-out) are ideal for OEM applications. QOU breakers are one, two or three pole thermal magnetic circuit breakers which provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip-free toggle mechanism with quick-make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. These QOU miniature circuit breakers can be DIN rail mounted, surface mounted or flush mounted using mounting feet. This two pole QOU miniature circuit breaker is rated as 20A, 120/240VAC. This unit provides 10 kA breaking capacity. A full line of accessories are available for these circuit breakers. The slotted box lugs will accept one 14 AWG to 2 AWG copper or aluminum wire. This unit includes a shunt trip. QOU circuit breakers are UL Listed and CSA Certified.
