Schneider Electric QOU2601021 Miniature Circuit Breaker 120/240V 60A

(No reviews yet) Write a Review

Write a Review

Schneider Electric QOU2601021 Miniature Circuit Breaker 120/240V 60A

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

QOU2601021

UPC:

7.85902E+11

MPN:

Condition:

New

Circularity Profile:

N/A

Mounting Mode:

unit mount

Awg Gauge:

AWG 14...AWG 2 aluminium/copper

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Mercury Free:

Yes

Electrical Connection:

slotted box lugs, line side || slotted box lugs, load side

Rohs Exemption Information:

Yes

Product Or Component Type:

miniature circuit-breaker

Height:

4.05 in

Eu Rohs Directive:

Compliant with Exemptions

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Range Of Product:

QOU

Width:

2.25 in

Tightening Torque:

45-45 lbf.in (AWG 14...AWG 2)

Circuit Breaker Type:

standard

Depth:

2.95 in

Warranty:

18 months

Circuit Breaker Application:

HACR rated

Halogen Content Performance:

Halogen free product

Sustainable Offer Status:

Green Premium product

Toxic Heavy Metal Free:

Yes

Line Rated Current:

60 A

Product Certifications:

CSA || IEC || UL Listed

[Ue] Rated Operational Voltage:

120/240 V AC || 120 V AC || 48 V DC
