Schneider Electric QOU3000 Non-Automatic Miniature Switch 240V 100A
SKU:
QOU3000
UPC:
785901060345
MPN:
Condition:
New
California Proposition 65:
WARNING: This product can expose you to chemicals including: Cadmium and cadmium compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Line Rated Current:
100 A
Rohs Exemption Information:
Yes
Product Or Component Type:
switch
Depth:
2.95 in
Eu Rohs Directive:
Compliant with Exemptions
Tightening Torque:
45-45 lbf.in (AWG 12...AWG 2/0)
Circuit Breaker Application:
HACR rated
Circularity Profile:
N/A
Halogen Content Performance:
Halogen free product
Sustainable Offer Status:
Green Premium product
Awg Gauge:
AWG 12...AWG 2/0 aluminium/copper
Range Of Product:
QOU
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Mounting Mode:
unit mount
Height:
4.45 in
Electrical Connection:
slotted box lugs, line side || slotted box lugs, load side
Mercury Free:
Yes
Warranty:
18 months
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
