Schneider Electric QOU3151021 Miniature Circuit Breaker 240V 15A
Schneider Electric
$474.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric QOU3151021 Miniature Circuit Breaker 240V 15A
QOU unit mount miniature circuit breakers (cable-in/cable-out) are ideal for OEM applications. QOU breakers are one, two or three pole thermal magnetic circuit breakers which provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip-free toggle mechanism with quick-make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. These QOU miniature circuit breakers can be DIN rail mounted, surface mounted or flush mounted using mounting feet. This three pole QOU miniature circuit breaker is rated as 15A, 240 VAC. This circuit breaker provides 10 kA breaking capacity. A full line of accessories are available for these circuit breakers. This breaker has a shunt trip with a 120/208/240 VAC control circuit voltage. The slotted box lugs will accept one 14 AWG to 2/0 AWG copper or aluminum wire. This circuit breaker has a maximum height of 4.05 inches, a maximum width of 3.00 inches and maximum depth of 2.95 inches. QOU circuit breakers are UL Listed and CSA Certified.
- Toxic Heavy Metal Free:
- Yes
- Width:
- 3 in
- Rohs Exemption Information:
- Yes
- Product Certifications:
- UL Listed || CSA || IEC
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Electrical Connection:
- slotted box lugs, line side || slotted box lugs, load side
- Circularity Profile:
- N/A
- Depth:
- 2.95 in
- Tightening Torque:
- 45-45 lbf.in (AWG 14...AWG 2)
- Range Of Product:
- QOU
- Halogen Content Performance:
- Halogen free product
- Height:
- 4.05 in
- Awg Gauge:
- AWG 14...AWG 2 aluminium/copper
- Circuit Breaker Type:
- standard
- Product Or Component Type:
- miniature circuit-breaker
- Mercury Free:
- Yes
- Mounting Mode:
- unit mount
- Sustainable Offer Status:
- Green Premium product
- [Ue] Rated Operational Voltage:
- 120/240 V AC || 240 V AC || 120 V AC || 48 V DC
- Circuit Breaker Application:
- HACR rated
- Eu Rohs Directive:
- Compliant with Exemptions
- Warranty:
- 18 months
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Line Rated Current:
- 15 A
