Schneider Electric QOU3201042 Miniature Circuit Breaker 240V 20A
SKU:
QOU3201042
UPC:
785901586616
MPN:
Condition:
New
Halogen Content Performance:
Halogen free product
Mounting Mode:
unit mount
[Ue] Rated Operational Voltage:
120/240 V AC || 240 V AC || 120 V AC || 48 V DC
Circuit Breaker Application:
HACR rated
Awg Gauge:
AWG 14...AWG 2 aluminium/copper
Line Rated Current:
20 A
Range Of Product:
QOU
Circuit Breaker Type:
standard
Toxic Heavy Metal Free:
Yes
Width:
3 in
Rohs Exemption Information:
Yes
Product Or Component Type:
miniature circuit-breaker
Tightening Torque:
45-45 lbf.in (AWG 14...AWG 2)
Product Certifications:
UL Listed || CSA || IEC
Height:
4.05 in
Warranty:
18 months
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Eu Rohs Directive:
Compliant with Exemptions
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Electrical Connection:
slotted box lugs, line side || slotted box lugs, load side
Mercury Free:
Yes
Depth:
2.95 in
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle...
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle...
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle...
QO and QOU Miniature Circuit Breakers, QOUR120, is ideal for OEM applications. Equipped with Rotated fixing lug QOU miniature circuit breakers are used for overcurrent protection and switching on...
