Schneider Electric QOU3205283 Miniature Circuit Breaker 240V 20A
Schneider Electric
$354.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric QOU3205283 Miniature Circuit Breaker 240V 20A
QO and QOU Miniature Circuit Breakers, QOU3205283, is ideal for OEM applications. QOU miniature circuit breakers are used for overcurrent protection and switching on both AC and DC electrical systems. These Breakers These Breakers provide a means to manually open a circuit. Comes with factory installed ring tongue terminal.
- Circuit Breaker Application:
- HACR rated
- Width:
- 2.25 in
- Toxic Heavy Metal Free:
- Yes
- Halogen Content Performance:
- Halogen free product
- Awg Gauge:
- AWG 14...AWG 2 aluminium/copper
- Line Rated Current:
- 20 A
- Mercury Free:
- Yes
- Electrical Connection:
- ring tongue, line side || ring tongue, load side
- Eu Rohs Directive:
- Compliant with Exemptions
- Circuit Breaker Type:
- standard
- Height:
- 4.05 in
- Product Or Component Type:
- miniature circuit-breaker
- Sustainable Offer Status:
- Green Premium product
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Mounting Mode:
- unit mount
- Circularity Profile:
- N/A
- Warranty:
- 18 months
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Rohs Exemption Information:
- Yes
- [Ue] Rated Operational Voltage:
- 120/240 V AC || 240 V AC || 120 V AC || 48 V DC
- Range Of Product:
- QOU
- Product Certifications:
- CSA || UL Listed || IEC
- Tightening Torque:
- 45-45 lbf.in (AWG 14...AWG 2)
- Depth:
- 2.95 in
- Brochure:
- View
- Catalog:
- View
- Datasheet:
- View
