Schneider Electric QOU3255283 Miniature Circuit Breaker 240V 25A
Schneider Electric
$354.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Mini circuit breaker, QOU, 25A, 3 pole, 240 VAC, 10kA, ring terminal
- Depth:
- 2.95 in
- Range Of Product:
- QOU
- Product Or Component Type:
- miniature circuit-breaker
- Warranty:
- 18 months
- Electrical Connection:
- ring tongue, line side || ring tongue, load side
- Circuit Breaker Type:
- standard
- Line Rated Current:
- 25 A
- Mercury Free:
- Yes
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Product Certifications:
- UL Listed || IEC || CSA
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Eu Rohs Directive:
- Compliant with Exemptions
- Circularity Profile:
- N/A
- [Ue] Rated Operational Voltage:
- 120/240 V AC || 240 V AC || 120 V AC || 48 V DC
- Circuit Breaker Application:
- HACR rated
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
- Rohs Exemption Information:
- Yes
- Sustainable Offer Status:
- Green Premium product
- Mounting Mode:
- unit mount
- Width:
- 2.25 in
- Height:
- 4.05 in
- Toxic Heavy Metal Free:
- Yes
- Tightening Torque:
- 45-45 lbf.in (AWG 14...AWG 2)
- Halogen Content Performance:
- Halogen free product
- Awg Gauge:
- AWG 14...AWG 2 aluminium/copper
- Brochure:
- View
- Catalog:
- View
- Datasheet:
- View
