Schneider Electric QOU325VH5283 Miniature Circuit Breaker 240V 25A

Schneider Electric QOU325VH5283 Miniature Circuit Breaker 240V 25A

Schneider Electric
SKU:
QOU325VH5283
|
UPC:
3606486146965
Availability:
Contact us to confirm availability and lead times.
$507.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
QO and QOU Miniature Circuit Breakers, QOU325VH5283, is ideal for OEM applications. QOU miniature circuit breakers are used for overcurrent protection and switching on both AC and DC electrical systems. These Breakers These Breakers provide a means to manually open a circuit. Comes with factory installed ring tongue terminal.QOU breakers are able to operate up to 22 kA short ciruit current. .
Additional Information
Depth:
2.95 in
Circularity Profile:
N/A
Sustainable Offer Status:
Green Premium product
Tightening Torque:
45-45 lbf.in (AWG 14...AWG 2)
[Ue] Rated Operational Voltage:
120/240 V AC
Halogen Content Performance:
Halogen free product
Warranty:
18 months
Eu Rohs Directive:
Compliant with Exemptions
Height:
4.05 in
Awg Gauge:
AWG 14...AWG 2 aluminium/copper
Line Rated Current:
25 A
Toxic Heavy Metal Free:
Yes
Product Or Component Type:
miniature circuit-breaker
Width:
2.25 in
Electrical Connection:
slotted ring tongue, line side || slotted ring tongue, load side
Circuit Breaker Type:
standard
Mercury Free:
Yes
Product Certifications:
IEC || UL Listed || CSA
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Mounting Mode:
unit mount
Range Of Product:
QOU
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Circuit Breaker Application:
HACR rated
Rohs Exemption Information:
Yes
