Schneider Electric QOU3601021 Miniature Circuit Breaker 240V 60A
SKU:
QOU3601021
UPC:
785901090366
MPN:
Condition:
New
Product Certifications:
CSA || UL Listed || IEC
Depth:
2.95 in
Mounting Mode:
unit mount
Mercury Free:
Yes
Warranty:
18 months
Line Rated Current:
60 A
Circuit Breaker Application:
HACR rated
[Ue] Rated Operational Voltage:
120/240 V AC || 240 V AC || 120 V AC || 48 V DC
Range Of Product:
QOU
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Eu Rohs Directive:
Compliant with Exemptions
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Sustainable Offer Status:
Green Premium product
Circularity Profile:
N/A
Tightening Torque:
45-45 lbf.in (AWG 14...AWG 2)
Height:
4.05 in
Product Or Component Type:
miniature circuit-breaker
Electrical Connection:
slotted box lugs, line side || slotted box lugs, load side
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle...
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle...
QO and QOU Miniature Circuit Breakers, QOU360, is ideal for OEM applications. QOU miniature circuit breakers are used for overcurrent protection and switching on both AC and DC electrical systems...
