Schneider Electric QOU3601200 Miniature Circuit Breaker 240V 60A

(No reviews yet) Write a Review
SKU:
QOU3601200
UPC:
785901166047
Condition:
New
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Rohs Exemption Information:
Yes
Circuit Breaker Application:
HACR rated
Product Certifications:
UL Listed || IEC || CSA
Width:
3 in
Awg Gauge:
AWG 14...AWG 2 aluminium/copper
[Ue] Rated Operational Voltage:
120/240 V AC || 240 V AC || 120 V AC || 48 V DC
Line Rated Current:
60 A
Sustainable Offer Status:
Green Premium product
California Proposition 65:
WARNING: This product can expose you to chemicals including: Cadmium and cadmium compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Range Of Product:
QOU
Circuit Breaker Type:
standard
Eu Rohs Directive:
Compliant with Exemptions
Halogen Content Performance:
Halogen free product
Circularity Profile:
N/A
Mercury Free:
Yes
Depth:
2.95 in
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Product Or Component Type:
miniature circuit-breaker
Tightening Torque:
45-45 lbf.in (AWG 14...AWG 2)
Height:
4.05 in
Mounting Mode:
unit mount
Warranty:
18 months
Electrical Connection:
slotted box lugs, line side || slotted box lugs, load side
$417.00

Description

QOU unit mount miniature circuit breakers (cable-in/cable-out) are ideal for OEM applications. QOU breakers are one, two or three pole thermal magnetic circuit breakers which provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip-free toggle mechanism with quick-make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. These QOU miniature circuit breakers can be DIN rail mounted, surface mounted or flush mounted using mounting feet. This three pole QOU miniature circuit breaker is rated as 60A, 240 VAC. This circuit breaker provides 10 kA breaking capacity. A full line of accessories are available for these circuit breakers. This breaker has an auxiliary switch. The factory installed quick connects will accept one 14 AWG to 2 AWG copper or aluminum wire. This circuit breaker has a maximum height of 4.05 inches, a maximum width of 3.00 inches and maximum depth of 2.95 inches. QOU circuit breakers are UL Listed and CSA Certified.
