Schneider Electric QOUR2253100 Miniature Circuit Breaker 120/240V 25A
SKU:
QOUR2253100
UPC:
785901825456
MPN:
Condition:
New
Awg Gauge:
AWG 14...AWG 2 aluminium/copper
Mercury Free:
Yes
Warranty:
18 months
Tightening Torque:
45-45 lbf.in (AWG 14...AWG 2)
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Mounting Mode:
unit mount
Height:
4.05 in
Circuit Breaker Application:
HACR rated
Eu Rohs Directive:
Compliant with Exemptions
Product Or Component Type:
miniature circuit-breaker
Circuit Breaker Type:
standard
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Sustainable Offer Status:
Green Premium product
Circularity Profile:
N/A
Width:
1.5 in
Range Of Product:
QOU
Depth:
2.95 in
Rohs Exemption Information:
Yes
Product Certifications:
CSA || IEC || UL Listed
[Ue] Rated Operational Voltage:
120/240 V AC || 120 V AC || 48 V DC
Halogen Content Performance:
Halogen free product
California Proposition 65:
WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
Line Rated Current:
25 A
Electrical Connection:
slotted box lugs, line side || slotted box lugs, load side
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle...
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle...
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle...
QOU unit mount miniature circuit breakers (cable-in/cable-out) are ideal for OEM applications. QOU breakers are one, two or three pole thermal magnetic circuit breakers which provide overcurrent...
