Schneider Electric REXL4TMB7 Mini Plug-In Timer 4C/O 24Vac

Schneider Electric REXL4TMB7 Mini Plug-In Timer 4C/O 24Vac

Schneider Electric
SKU:
REXL4TMB7
|
UPC:
3389119400084
$56.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
This Harmony REXL ON-delay timer can be set between 0.1 seconds and 100 hours. It provides function A and it uses plug-in mounting. This modular ON-delay timer is ideal for providing timing control in automation systems such as automatic door opening, alarm, lighting in toilets and car park barriers. It is a plug-in device, meaning it is quick and easy to install with the need for tools. It also offers a sealable cover, simple and precise settings with rotary trimmers. It is designed for socket plug in, this allows quick and easy installation and minimizes set up and repair time. Single function timer for a simple integration in hard-wired logic schematics, ideal for refurbishment of old installations without using a PLC. 0 0 0 0 0 0 0 0 0 0 0 0
Additional Information
Reset Time:
250 ms after time delay, on de-energisation || 50 ms during time delay, on de-energisation
China Rohs Regulation:
X
Ambient Air Temperature For Storage:
-40-70 °C
Vibration Resistance:
0.35 mm 10-55 Hz)IEC 60068-2-6
Immunity To Voltage Dips:
>= 95 % / 1 s IEC 61000-4-11 || 30 % / 10 ms IEC 61000-4-11 || 60 % / 100 ms IEC 61000-4-11
Disturbance Radiated/Conducted:
class B EN 55022 (EN 55011 group 1)
Standards:
IEC 60601-1 || 89/336/EEC || IEC 61812-1 || IEC 60601-2 || 73/23/EEC || 93/68/EEC || IEC 61000-6-2 || EN 50081-2
Dielectric Strength:
2 kV 1 mA/1 minute 50 Hz IEC 60601-1 || 2 kV 1 mA/1 minute 50 Hz IEC 61812-1
Voltage Drift:
+/- 0.2 %/V
Contacts Material:
cadmium free
Immunity To Radioelectric Fields:
10 V 0.15...80 MHz)IEC 61000-4-6 level 3
Immunity To Microbreaks:
5 ms
Fixing Mode:
plug-in socket)
Temperature Drift:
0.05 %/°C
Time Delay Type:
power on-delay
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Line Rated Current:
5 A AC
Product Or Component Type:
single function relay
Electrical Durability:
100000 cycles 250 V AC resistive
Temporary Permissible Current:
10 A < 10 s
Ambient Air Temperature For Operation:
-20-60 °C
Range Of Product:
Harmony Timer Relays
Component Name:
REXL
California Proposition 65:
WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr
Surge Withstand:
2 kV IEC 61000-4-5 level 3
Mercury Free:
Yes
Resistance To Electromagnetic Fields:
10 V/m IEC 61000-4-3 level 3
Maximum Switching Capacity:
4 x 5 A
Ip Degree Of Protection:
IP50 conforming to IEC 60529
Net Weight:
0.05 kg
Sustainable Offer Status:
Green Premium product
Power Consumption In Va:
1.7 VA
[Ui] Rated Insulation Voltage:
250 V IEC 255 Group C || 250 V VDE 0010
Contacts Type And Composition:
4 C/O
Output Overvoltage Protection:
2 J
Creepage Distance:
4 kV/3 IEC 60664-1
Minimum Switching Current:
100 mA
Resistance To Fast Transients:
2 kV IEC 61000-4-4 level 3
[Us] Rated Supply Voltage:
24 V AC 50/60 Hz
Mechanical Durability:
10000000 cycles
Voltage Range:
0.85...1.15 Us
Resistance To Electrostatic Discharge:
6 kV in contact IEC 61000-4-2 level 3 || 8 kV in air IEC 61000-4-2 level 3
Environmental Disclosure:
ENVPEP1310019EN
Warranty:
18 months
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Relative Humidity:
95-95 % without condensation IEC 60068-2-6
Setting Accuracy Of Time Delay:
10 % at full scale 25 °C IEC 61812-1
Circularity Profile:
N/A
Product Certifications:
UL || cUL
Discrete Output Type:
relay
Time Delay Range:
6...60 s || 1...10 s || 1...10 h || 1...10 min || 6...60 min || 10...100 h || 0.1...1 s
Rohs Exemption Information:
Yes
Local Signalling:
for output in operation 1 LED (red) || for power ON 1 LED (yellow)
Repeat Accuracy:
+/- 0.5 %
