Schneider Electric RSL1PVFU Slim Relay+Socket 1C/O Led 110Vacdc Scrw Pack of 10
Schneider Electric
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This Harmony RSL slim interfacing plug-in relay has a coil control voltage of 60V DC and has 1 changeover contact SPDT (single pole double throw) with a rating of 6A. It has large choice of number of contacts for high rated current use. It also offers LED indicator and protection circuit. It helps to reduce the size of enclosures and increase machine reliability, you can mount nearly everywhere. One of the slimiest interface relay on the market, with 6mm width, it can be installed nearly anywhere. It is compatible with high breaking capacity or low-level current application requirements. Workability for hard-wired logic automated systems to complement the functions of industrial programmable logic controllers (PLCs). Status display with LED, clearly signal both in the day and night. 0 0 0 0 0 0 0 0 0 0
- Reach Free Of Svhc:
- Yes
- Average Resistance:
- 20500 Ohm DC 23 °C +/- 10 %
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Test Levels:
- level A group mounting
- Tightening Torque:
- < 0.5 N.m M2.5
- Terminals Description Iso N°1:
- (A1-A2)CO || (11-12-14)OC
- Depth:
- 95 mm
- Range Of Product:
- Harmony Electromechanical Relays
- Safety Reliability Data:
- B10d = 60000
- Operating Rate:
- <= 72000 cycles/hour no-load || <= 360 cycles/hour under load
- Height:
- 78.6 mm
- Marking:
- CE
- [Uc] Control Circuit Voltage:
- 60 V DC
- Product Or Component Type:
- pre-assembled plug-in relay with socket
- Maximum Switching Voltage:
- 277 V
- Mounting Support:
- 35 mm symmetrical DIN rail
- [Ithe] Conventional Enclosed Thermal Current:
- 6 A -40-55 °C
- Maximum Switching Capacity:
- 1500 VA || 150 W
- Net Weight:
- 0.029 kg
- Reset Time:
- 20 ms
- Status Led:
- with
- Ambient Air Temperature For Operation:
- -40-70 °C
- Operating Time:
- 5 ms reset || 12 ms
- Contacts Material:
- silver alloy (AgSnO2)
- [Ie] Rated Operational Current:
- 6 A 1 C/O AC-1/DC-1)IEC/UL
- Device Presentation:
- complete product
- Warranty:
- 18 months
- Load Current:
- 6 A 250 V AC 0.5 mm mounting distance
- Dielectric Strength:
- 1000 V AC between contacts || 4000 V AC between coil and contact
- Phenolic Free Solution:
- Yes
- Width:
- 6.2 mm
- Shock Resistance:
- 10 gn 11 ms) in operation IEC 60068-2-27 || 5 gn 11 ms) not operating IEC 60068-2-27
- [Ui] Rated Insulation Voltage:
- 250 V IEC || 277 V cUL
- Control Type:
- without push-button
- China Rohs Regulation:
- X
- Electrical Durability:
- 60000 cycles resistive, 6 A 250 V, AC-1
- Minimum Switching Voltage:
- 12 V
- Ambient Air Temperature For Storage:
- -40-85 °C
- Contact Terminal Arrangement:
- separate
- Protection Category:
- RT III
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr
- Sustainable Offer Status:
- Green Premium product
- [Uimp] Rated Impulse Withstand Voltage:
- 6 kV IEC
- Connections - Terminals:
- screw connectors, 1 x 0.2...1 x 2.5 mm² AWG 24...AWG 14) flexible with cable end || screw connectors, 1 x 0.2...1 x 2.5 mm² AWG 24...AWG 14) solid without cable end
- Standards:
- CSA C22.2 No 14 || IEC 61810-1 || UL 508
- Circularity Profile:
- ENVEOLI1405004EN
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Rohs Exemption Information:
- Yes
- Minimum Switching Capacity:
- 120 mW
- Average Coil Consumption:
- 0.17 W, DC
- Series Name:
- interface relay
- Sale Per Indivisible Quantity:
- 10
- Minimum Switching Current:
- 100 mA
- Toxic Free:
- Yes
- Environmental Disclosure:
- ENVPEP1405004EN
- Contacts Type And Composition:
- 1 C/O
- Input Voltage:
- 110 V AC/DC 88...126.5 V)
- Ip Degree Of Protection:
- IP40 conforming to IEC 60529
- Fixing Mode:
- plastic compression spring
- Vibration Resistance:
- 10 gn +/- 1 mm 10-150 Hz)10 cycles not operating IEC 60068-2-6 || 5 gn +/- 1 mm 10-150 Hz)10 cycles in operation IEC 60068-2-6
- Shape Of Pin:
- flat (PCB type)
- Toxic Heavy Metal Free:
- Yes
- Product Certifications:
- CSA || UL || GOST
- Contact Operation:
- standard
- Mercury Free:
- Yes
- Mechanical Durability:
- 10000000 cycles
- Drop-Out Voltage Threshold:
- >= 0.05 Uc
- Device Short Name:
- RSL
- Operating Position:
- any position
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
