Maximum Radial Force Fr:
730 N 1000 rpm || 580 N 2000 rpm || 510 N 3000 rpm || 460 N 4000 rpm || 430 N 5000 rpm || 400 N 6000 rpm
Stator Resistance:
2.7 Ohm
Holding Torque:
3 N.m
Stator Inductance:
20.3 mH
Maximum Mechanical Speed:
8000 rpm
Net Weight:
3.8 kg
Electrical Connection:
rotatable right angled connector
Circle Diameter Of The Mounting Holes:
82 mm
Type Of Cooling:
natural convection
Rotor Inertia:
0.807 kg.cm²
Continuous Power:
1330 W
Mounting Holes Diameter:
5.5 mm
Shaft Length:
30 mm
Encoder Type:
absolute single turn SinCos Hiperface
Maximum Current Irms:
17 A
Nominal Output Power:
460 W 115 V single phase || 880 W 230 V single phase || 1450 W 400 V three phase || 1550 W 480 V three phase
Nominal Torque:
2.95 N.m 115 V single phase || 2.8 N.m 230 V single phase || 2.1 N.m 400 V three phase || 2.1 N.m 480 V three phase
Circularity Profile:
N/A
Number Of Mounting Holes:
4
Length:
254 mm
Centring Collar Diameter:
60 mm
Sustainable Offer Status:
Green Premium product
Rohs Exemption Information:
Yes
Peak Stall Torque:
11.3 N.m 115...480 V three phase
Maximum Axial Force Fa:
80 N
Mercury Free:
Yes
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
