Schneider Electric SSD1A320BDC3 Solid State Relay-Din Rail, Single Phase
Schneider Electric
$79.03
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This solid state DIN rail mounted relay belongs to the Schneider Electric Harmony solid state relays range. This electrical relay mounts on 35mm DIN rail and comes with a secure mounting latch. This is a 20A power rated relay with pluggable spring input contactor type configuration and zero voltage switching. This single-phase relay has a IP20 built-in heat sink and a built-in transient overvoltage protection. It is controlled with a 4Vdc to 32Vdc input, has a rated load voltage of 48Vac to 600Vac. It also has a LED input voltage status indicator and clip-in legend for easy identification. It weighs 0.301Kg and its dimensions are, 22.5mm wide, 133.8mm deep, 91.9mm high. It is the ideal solution for packaging, plastic molding, textile, and heating furnace applications. This relay conforms to international standards like EN/IEC 60068, IEC 61373, UL 508, CSA C22.2 No 14-13 and certifications like UL and CSA. Besides the existing standard screw connection for input and output, SSD provides more wiring options like the spring or screw pluggable input connectors, and telescopic or clamp cage output terminals.
- Motor Power Kw:
- 0.37 kW/0.5 hp at 120 V AC || 1.12 kW/1.5 hp at 240 V AC || 2.24 kW/3 hp at 480 V AC
- Shock Resistance:
- 50 gn for 11 ms (peak acceleration) , longitudinal position conforming to IEC 60068-2-27 || 30 gn for 11 ms (peak acceleration) , vertical position conforming to IEC 60068-2-27
- Standards:
- IEC 61373:class B: category 1 || IEC 60947-4-3 || IEC 62314 || IEC 60950-1 || CSA C22.2 No 14-13 || UL 508
- [Uc] Control Circuit Voltage:
- 4...32 V DC
- Pollution Degree:
- 2
- Dielectric Strength:
- 4 kV AC for input/output circuit || 4 kV AC for input or output to case
- Product Configuration Type:
- contactor configuration with pluggable spring input
- Absolute Maximum Voltage:
- 1200 V
- Output Voltage:
- 48...600 V AC
- Network Frequency:
- 47...440 Hz
- Maximum I²T For Fusing:
- 409 A².s for 10 ms || 375 A².s for 8.33 ms
- Minimum Switching Voltage:
- 4 V DC turn-on
- Ip Degree Of Protection:
- IP20
- Number Of Channels:
- 1
- Device Presentation:
- complete product
- Local Signalling:
- for control voltage LED (green)
- Ambient Air Temperature For Storage:
- -40-100 °C
- Range Of Product:
- Harmony Solid State Relays
- Net Weight:
- 0.301 kg
- Line Rated Current:
- 20 A
- Vibration Resistance:
- 0.75 mm (f = 10-150 Hz) conforming to IEC 60068-2-6
- Tightening Torque:
- 2...2.2 N.m for load output || 18...20 lb.in for load output
- Inrush Current:
- 300 A at 60 Hz
- Response Time:
- 0.5 cycle (turn-on) || 0.5 cycle (turn-off)
- Overvoltage Category:
- III
- Solid State Output Type:
- zero voltage switching
- Circularity Profile:
- ENVEOLI1508007EN
- Width:
- 22.5 mm
- Rohs Exemption Information:
- Yes
- Coordination Type:
- type 1 || type 2
- Phase:
- 1 phase
- Electromagnetic Compatibility:
- electrostatic discharge 6 kV criteria A contact discharge conforming to IEC 61000-4-2 || electrostatic discharge 8 kV criteria A air discharge conforming to IEC 61000-4-2 || conducted RF disturbances 10 V, 0.15...80 MHz criteria A level 3 conforming
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Maximum Voltage Drop:
- <1.3 V on-state
- Maximum Switching Voltage:
- 1 V DC turn-off
- Connections - Terminals:
- plug-inspring terminals, clamping connection capacity:0.13...3.30 mm², AWG 26...AWG 12 for input || telescopic screw, clamping connection capacity:0.75...10 mm², AWG 20...AWG 8 for output
- Sustainable Offer Status:
- Green Premium product
- Insulation Resistance:
- 1000 MOhm at 500 V DC
- Flame Retardance:
- V-0 conforming to UL 94
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Ambient Air Temperature For Operation:
- -40-80 °C
- Input Current Limits:
- 10-15 mA
- China Rohs Regulation:
- X
- Dv/Dt:
- 500 V/µs off-state at maximum rated voltage
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Product Or Component Type:
- solid state relay up to 20 A
- Rated Duty:
- uninterrupted
- Load Current:
- 0.1-20 A
- Device Short Name:
- SSD1
- Mercury Free:
- Yes
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Height:
- 91.9 mm
- Mounting Support:
- 35 mm symmetrical DIN rail conforming to IEC 60715
- Output Switching Mode:
- zero voltage switching
- Environmental Disclosure:
- ENVPEP1508007EN
- Contact Form:
- Form 5 semiconductor output DOL contactor
- [Uimp] Rated Impulse Withstand Voltage:
- 6 kV for input/output circuit || 6 kV for input or output to case
- Power Factor:
- 0.5 with maximum load
- Maximum Leakage Current:
- 1 mA off-state
- Depth:
- 133.8 mm
