Schneider Electric STBCPS2111K Aux Power Supply Kit Conn,Base

Schneider Electric STBCPS2111K Aux Power Supply Kit Conn,Base

Schneider Electric
SKU:
STBCPS2111K
|
UPC:
3595863949223
Availability:
Factory stock
$200.78
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
This product is part of the Modicon STB range, an offer of modular distributed I/O. This auxiliary power supply kit is for logic I/O module. It is an auxiliary power supply kit with a rated supply voltage of 24V DC, an output current of 1.2A, an input current of 400mA and output voltage of 5.25V ±0.21% logic bus. This product is compatible with most major fieldbus networks. It is furnished with 2-pin removable connector for power supply. It is an IP20 rated product. It is suitable for packaging, bottling, assembly, distribution, textile, printing and semiconductor machines applications. This product is certified by CE, FM Class 1 Division 2, CSA and UL. The kit includes terminal spring clamp connector, terminal screw type connector, STBXBA2100 base and STBCPS2111 module. The Modicon LMC058 is the optimum solution for axis control and positioning, including automation functions. It forms a part of flexible machine control approach, a key component of MachineStruxure.
Additional Information
Warranty:
18 months
Input Current:
400 mA
Supply Circuit Type:
DC
Ambient Air Temperature For Operation:
-25-70 °C without derating)
Ambient Air Temperature For Storage:
-40-85 °C
Kit Composition:
terminal spring clamp connector || STBXBA2100 base || STBCPS2111 module || terminal screw type connector
Rohs Exemption Information:
Yes
Operating Altitude:
<= 6561.68 ft (2000 m)
Mercury Free:
Yes
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Output Voltage:
5.25 V +/- 0.21 % logic bus
Marking:
CE
Product Specific Application:
supply for logic of I/O module
Relative Humidity:
95-95 % 60-60 °C without condensation
Overvoltage Category:
II
Shock Resistance:
30 gn 11 ms IEC 88 reference 2-27
Electromagnetic Compatibility:
immunity to electromagnetic interference IEC 61131-2
Vibration Resistance:
3 gn 58-150 Hz 35 x 7.5 mm symmetrical DIN rail || 5 gn 58-150 Hz 35 x 15 mm symmetrical DIN rail || +/-0.35 mm 10-58 Hz
Supply Voltage Limits:
19.2-30 V
Ip Degree Of Protection:
IP20 conforming to IEC 61131-2 class 1
Output Voltage Type:
DC
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Electrical Connection:
2 pins for removable connector power supply
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Range Of Product:
Modicon STB distributed I/O solution
Product Or Component Type:
auxiliary power supply kit
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Power Supply Output Current:
1.2 A
Pollution Degree:
2 IEC 60664-1
China Rohs Regulation:
X
Product Certifications:
UL || CSA || FM Class 1 Division 2
[Us] Rated Supply Voltage:
24 V
