Schneider Electric

Schneider Electric TCSESL043F23F0 Connexium Lite Managed Switch - 4Tx

SKU:

TCSESL043F23F0

UPC:

3.60648E+12

MPN:

Condition:

New

Depth:

79 mm

Transmission Support Medium:

twisted shielded pairs cable CAT 5E copper cable

Redundancy:

RSTP

Ambient Air Temperature For Operation:

0-60 °C

Standards:

UL 61010

Width:

25 mm

Warranty:

18 months

Diagnostics Run Time:

log file

Supply Voltage Limits:

9.6-32 V DC SELV

Maximum Cable Distance Between Devices:

100 m copper cable

Concept:

Transparent Ready

Net Weight:

0.103 kg

Communication Service:

TFTP || port monitoring

Directives:

2014/35/EU - low voltage directive || 2014/30/EU - electromagnetic compatibility

Product Certifications:

CE || UL || RCM

China Rohs Regulation:

X

Height:

114 mm

[Us] Rated Supply Voltage:

12...24 V

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Cybersecurity:

enable/disable communication ports

Product Or Component Type:

Ethernet TCP/IP managed switch

Port Ethernet:

10/100BASE-TX - 4 copper cable

Integrated Connection Type:

shielded RJ45 copper cable

Maximum Number Of Switches In Cascade:

unlimited

Power Consumption In W:

2.35 W

Maximum Number Of Switches In A Ring:

50

Rohs Exemption Information:

Yes

Environmental Disclosure:

ENVPEP100304EN

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Ethernet Service:

configuration via web server || multicast filtering || syslog || SNMP-Traps

Range Of Product:

ConneXium

Local Signalling:

for power supply 1 LED (green) || for data rate (ETH LINK) 1 LED per channel (yellow) || for link status 1 LED per channel (green)

Relative Humidity:

5-95 % non-condensing

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Mounting Support:

35 mm symmetrical DIN rail

Sustainable Offer Status:

Green Premium product

Ip Degree Of Protection:

IP30

Circularity Profile:

ENVEOLI1003004EN

Electrical Connection:

removable connector 3 ways power supply

Marking:

CE || cULus || RCM

Ethernet Cabling System:

TF switches

Communication Port Protocol:

Ethernet TCP/IP || HTTP || HTTPS || SNMP || LLDP

Mercury Free:

Yes
