Schneider Electric TM3XREC1 Module Tm3-Bus Receiver

(No reviews yet) Write a Review

Write a Review

Schneider Electric TM3XREC1 Module Tm3-Bus Receiver

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

TM3XREC1

UPC:

3.60648E+12

MPN:

Condition:

New

Power Supply Output Current:

560-560 mA 5 V expansion bus || 560-560 mA 24 V expansion bus

Circularity Profile:

ENVEOLI1403011EN

Rohs Exemption Information:

Yes

Depth:

73.3 mm

Vibration Resistance:

3.5 mm 5-8.4 Hz DIN rail || 3 gn 8.4-150 Hz DIN rail || 3.5 mm 5-8.4 Hz panel || 3 gn 8.4-150 Hz panel

Electromagnetic Emission:

radiated emissions 40 dBμV/m QP class A 10 m)30-230 MHz IEC 55011 || radiated emissions 47 dBμV/m QP class A 10 m)230-1000 MHz IEC 55011

Resistance To Electromagnetic Fields:

10 V/m 80 MHz...1 GHz IEC 61000-4-3 || 3 V/m 1.4 GHz...2 GHz IEC 61000-4-3 || 1 V/m 2...2.7 GHz IEC 61000-4-3

Electrical Connection:

RJ45 connector for connecting the bus transmitter || removable screw terminal block, 3 for connecting the 24 V DC power supply

Shock Resistance:

15 gn 11 ms

Ip Degree Of Protection:

IP20 with protective cover in place

Resistance To Conducted Disturbances:

10 V 0.15...80 MHz IEC 61000-4-6 || 3 V spot frequency (2, 3, 4, 6.2, 8.2, 12.6, 16.5, 18.8, 22, 25 MHz) Marine specification (LR, ABS, DNV, GL)

Current Consumption:

40 mA 24 V DC via bus connector

Ambient Air Temperature For Storage:

-40-70 °C

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Marking:

CE

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Ambient Air Temperature For Operation:

-10-55 °C horizontal installation) || -10-50 °C vertical installation)

Maximum Power Dissipation In W:

1 W

Mounting Support:

top hat type TH35-15 rail IEC 60715 || top hat type TH35-7.5 rail IEC 60715 || plate or panel with fixing kit

Net Weight:

0.075 kg

China Rohs Regulation:

X

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Maximum Number Of I/O Expansion Module:

7

Width:

23.65 mm

Standards:

Class I Division 2 Groups A/B/C/D CSA C22.2 No 213 || Class I Division 2 Groups A/B/C UL 1604 || CSA C22.2 No 142 || IEC 61131-2 || UL 508

Storage Altitude:

0-3000 m

Cable Distance Between Devices:

0.5-5 mm extension cable 2 RJ45 between receiver and transmitter

Environmental Disclosure:

ENVPEP1403011EN

Local Signalling:

for power supply 1 LED (green) || for link status 1 LED (green)

Height:

90 mm

Sustainable Offer Status:

Green Premium product

Range Compatibility:

Modicon M221 || Modicon M251 || Modicon M241 || Modicon M262

[Us] Rated Supply Voltage:

24 V DC external supply - 15...20 %)

Pvc Free:

Yes

Mercury Free:

Yes

Pollution Degree:

2

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Product Or Component Type:

remote receiver module

Relative Humidity:

5-95 % without condensation

Resistance To Electrostatic Discharge:

8 kV in air IEC 61000-4-2 || 6 kV on contact IEC 61000-4-2

Range Of Product:

Modicon TM3

Product Certifications:

Merchant Navy || GOST || C-tick || CSA HazLoc || CE || UKCA || RCM || EAC || cULus

Operating Altitude:

0...6561.68 ft (0...2000 m)
