Schneider Electric TM5NCO1 Canopen Fieldbus Interface Module

Schneider Electric TM5NCO1 Canopen Fieldbus Interface Module

Schneider Electric
SKU:
TM5NCO1
|
UPC:
3595864093031
Availability:
Contact us to confirm availability and lead times.
$293.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
This product is part of the Modicon TM5 range, an High-Performance and Safe IP20 Modular I/O System. This is a bus coupler designed for creating distributed IO islands on CANopen fieldbus, exchanging data between controller and distributed IO. Its access method is based on CSMA-MA, multi-master protocol. This is a bus coupler module designed for creating distributed IO islands on the Canopen fieldbus. This bus coupler works with an electronic power distribution module, a bus base and a terminal block. It has a 9-way SUB-D connector ISO 11898, with a 10 to 1000 Kbps data transmission rate. It weighs 0.080kg. It measures 25mm wide, 99mm high, 75mm deep. The Modicon TM5 meets the typical requirements of production and packaging machinery, as well as material handling and assembly systems. This product is certified by GOST-R, C-Tick, cULus and CSA. It meets IEC 61131-2, UL 508, CSA C22.2 No 213 and CSA C22.2 No 142 standards. It is compatible with Modicon M258 logic controllers, Modicon LMC058/LMC078 motion controllers. It is installed by mounting on a 35mm DIN rail. This modular IO system provides a flexible and scalable configuration of remote or distributed IO islands by connection with Modicon and PacDrive 3 controllers. Flexible and scalable, designed for complex machines.
Additional Information
Integrated Connection Type:
1 isolated serial link, male SUB-D 9 CANopen, 10, 20, 50, 125, 250, 500, 800, 1000 Kbit/s and autodetected
Vibration Resistance:
1 gn 8.4-150 Hz DIN rail || 3.5 mm 5-8.4 Hz DIN rail
Toxic Heavy Metal Free:
Yes
Disturbance Radiated/Conducted:
CISPR 11
Standards:
CSA C22.2 No 213 || IEC 61131-2 || UL 508 || CSA C22.2 No 142
Reach Regulation:
Free of Substances of Very High Concern above the threshold
Operating Altitude:
0...6561.68 ft (0...2000 m)
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Resistance To Fast Transients:
1 kV IEC 61000-4-4 I/O) || 1 kV IEC 61000-4-4 shielded cable) || 2 kV IEC 61000-4-4 power lines)
Resistance To Electromagnetic Fields:
1 V/m 2...2.7 GHz IEC 61000-4-3 || 10 V/m 80 MHz...2 GHz IEC 61000-4-3
Product Certifications:
cULus || C-tick || CSA || GOST-R
Electromagnetic Compatibility:
EN/IEC 61000-4-6
Ambient Air Temperature For Storage:
-40-70 °C
Pollution Degree:
2 IEC 60664
Range Of Product:
Modicon TM5
Mercury Free:
Yes
Storage Altitude:
0-3000 m
Ambient Air Temperature For Operation:
-10-55 °C without derating horizontal installation) || -10-60 °C with derating factor horizontal installation) || -10-50 °C vertical installation)
Electrical Connection:
removable spring terminal block
Warranty:
18 months
Range Compatibility:
Modicon LMC058 || Modicon LMC078 || Modicon M258
Pvc Free:
Yes
Rohs Exemption Information:
Yes
Marking:
CE
Relative Humidity:
5-95 % without condensation
Surge Withstand:
0.5 kV differential mode IEC 61000-4-5 || 1 kV common mode IEC 61000-4-5
Ip Degree Of Protection:
IP20IEC 61131-2
Resistance To Electrostatic Discharge:
4 kV on contact IEC 61000-4-2 || 8 kV in air IEC 61000-4-2
Product Or Component Type:
CANopen communication module
Environmental Disclosure:
ENVPEP1511025EN
China Rohs Regulation:
X
Product Compatibility:
motion controller || logic controller
Maximum Power Dissipation In W:
1.5 W
Device Composition:
interface module || bus base ordered separately || power supply ordered separately || terminal block ordered separately
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Local Signalling:
1 LED green/red power supply (PWR) || 1 LED green/red CAN status (RUN) || 1 LED red CAN status (ERROR) || 1 LED yellow controller communication status on TM5 bus (TxD)
Net Weight:
0.05 kg
Sustainable Offer Status:
Green Premium product
Color:
White
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Circularity Profile:
ENVEOLI1511025EN
Reach Free Of Svhc:
Yes
Current Consumption:
300 mA
Shock Resistance:
15 gn 11 ms
