Schneider Electric TM5SDO2TFS Mod. Fs 2Do 24Vdc Tr 0.5A
Schneider Electric
$270.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This product is part of the Modicon TM5 range, an High-Performance and Safe IP20 Modular I/O System. This safety discrete output module provides 2 outputs, 24V DC, transistor 0,5A. There is an isolation between channel and bus at 500V AC. This safety module, associated with TM5CSLC safety logic controller provides distributed safety solutions on Sercos bus up to SIL 3, Cat. 4, PL e, SIL CL3. It features 2 LEDs for power supply, 2 LEDs for safety status and 20 LEDs for input status signaling. It is furnished with 2 wires for electrical connection. Its housing colour is red. It weighs 0.025kg. It measure 75mm deep, 25mm wide, 99mm high. The Modicon TM5 meets the typical requirements of production and packaging machinery, as well as material handling and assembly systems. This product is certified by GOST-R, C-Tick, cULus and CSA. It meets IEC 61131-2, UL 508, CSA C22.2 No 213 and CSA C22.2 No 142 standards. It is compatible with Modicon TM5CSLC safety logic controller. It is installed by mounting on a 35mm DIN rail. This modular IO system provides a flexible and scalable configuration of remote or distributed IO islands by connection with Modicon and PacDrive 3 controllers. Flexible and scalable, designed for complex machines.
- Discrete Output Logic:
- source
- Product Certifications:
- CSA || GOST-R || cULus
- Marking:
- CE
- Local Signalling:
- 1 LED green power supply || 1 LED red power supply || 2 LEDs red safety status || 2 LEDs red/orange output status
- Pvc Free:
- Yes
- Range Of Product:
- Modicon TM5
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- [Ures] Residual Voltage:
- 120 mV without OSSD
- Peak Output Current:
- 0
- Current Per Channel:
- 0.5 A
- Maximum Power Consumption In W:
- 0.25 W bus || 0.98 W internal
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Sustainable Offer Status:
- Green Premium product
- Toxic Heavy Metal Free:
- Yes
- Pollution Degree:
- 2 IEC 60664
- Color:
- Red
- Vibration Resistance:
- 1 gn 8.4-150 Hz DIN rail || 3.5 mm 5-8.4 Hz
- Safety Level:
- SIL 3 IEC 61508 || SIL 3 IEC 62061 || PL = e EN 13849-1
- Switching Frequency:
- <= 500 Hz resistive
- Maximum Current Per Output Common:
- 0.0416666666666667
- Discrete Output Number:
- 2
- Range Compatibility:
- PacDrive LMC motion controller
- Protection Type:
- short-circuit protection || overload protection
- Ip Degree Of Protection:
- IP20EN 60529
- Isolation:
- 500 Vrms AC insulation between channel and bus || no insulation between channels
- Ambient Air Temperature For Operation:
- -10-50 °C vertical installation) || -10-55 °C horizontal installation)
- Ambient Air Temperature For Storage:
- -40-70 °C
- Storage Altitude:
- 0-3000 m
- Output Voltage:
- 24 V DC
- Electrical Connection:
- 2 wires
- Standards:
- CSA C22.2 No 142 || EN 13849-1 || IEC 61508 || IEC 62061 || UL 508 || IEC 61131-2
- Output Voltage Limits:
- 20.4...28.8 V
- Electromagnetic Compatibility:
- electrostatic discharge immunity test, 4 kV on contact EN/IEC 61000-4-2 || conducted and radiated emissions CISPR 11 || electrostatic discharge immunity test, 8 kV in air EN/IEC 61000-4-2 || susceptibility to electromagnetic fields, 10 V/m 80...2000
- Warranty:
- 18 months
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Maximum Leakage Current:
- 10 µA when switched off
- Mercury Free:
- Yes
- Product Compatibility:
- PacDrive LMC Pro 2 || PacDrive LMC Pro || PacDrive LMC Eco
- Environmental Disclosure:
- ENVPEP1511026EN
- Safety Reliability Data:
- MTTFd > 100 years || PFD < 1E-5 || PFH < 1E-9
- Shock Resistance:
- 15 gn 11 ms
- Product Or Component Type:
- safety dc discrete output module
- Rohs Exemption Information:
- Yes
- Relative Humidity:
- 5-95 % without condensation
- Discrete Output Type:
- solid state
- Net Weight:
- 0.025 kg
- China Rohs Regulation:
- X
- Circularity Profile:
- ENVEOLI1511026EN
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Operating Altitude:
- 0...6561.68 ft (0...2000 m)
