Schneider Electric TMC4AQ2 Cartridge M241-4 Analog Outputs

(No reviews yet) Write a Review
SKU:
TMC4AQ2
UPC:
3.60648E+12
Condition:
New
Height:
50 mm
Depth:
21 mm
Maximum Cable Distance Between Devices:
twisted shielded pairs cable <30 m input
Product Compatibility:
Modicon M241C
Circularity Profile:
ENVEOLI1403017EN
Pvc Free:
Yes
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Electrical Connection:
1 x 1.5 mm² 1 spring terminal block pitch 3.81 mm for outputs and supply
Stabilisation Time:
10 ms
Product Or Component Type:
analogue output cartridge
Lsb Value:
1 mV 0...10 V voltage || 2 µA 4...20 mA current
Absolute Accuracy Error:
+/- 0.2 % of full scale at 25 °C
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Load Type:
resistive
Cross Talk:
80 dB
Width:
34 mm
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Analogue Output Number:
2
Insulation:
between output and internal logic 500 V DC || non-insulated between outputs
Immunity To Microbreaks:
10 ms
Analogue Output Resolution:
16 bits
China Rohs Regulation:
X
Repeat Accuracy:
+/- 0.5 %FS
Range Of Product:
Modicon M241
Net Weight:
0.055 kg
Type Of Cable:
twisted shielded pairs cable
Mercury Free:
Yes
Supply Voltage Limits:
20.4-28.8 V
Analogue Output Type:
current 4...20 mA || voltage 0...10 V
Conversion Time:
10 ms + 1 controller cycle time
Non-Linearity:
+/- 0.05 %FS
Sustainable Offer Status:
Green Premium product
Environmental Disclosure:
ENVPEP1403017EN
Rohs Exemption Information:
Yes
Local Signalling:
for PWR 1 LED (green)
Output Ripple:
+/- 20 mV
Load Impedance Ohmic:
<= 500 Ohm current || >= 2 kOhm voltage
Temperature Drift:
+/- 0.006 %FS/°C
Catalog:
View
Datasheet:
View
$211.25

Description

cartridge M241 - 2 analog outputs This product is part of the Modicon M241 range, an offer of logic controllers for performance demanding applications. This analogue output cartridge is for Modicon M241 logic controllers. It provides 2 analogue current outputs with 16bit resolution. The maximum twisted shielded pairs cable distance between devices is <30m for input. There is an insulation between output and internal logic at 500V DC and no insulation between outputs. It is furnished with spring terminal for electrical connection. Its dimensions are 34mm (Width) x 21mm (Depth) x 50mm (Height). It weighs 0.055kg. The Modicon M241 logic controllers are designed for high-performance compact machines incorporating speed and position control functions. This product is certified by CE, IACS E10, RCM, CSA, CULus. It meets ANSI/ISA 12-12-01, CSA C22.2 No 142, CSA C22.2 No 213, EN/IEC 61131-22007, marine specification (LR, ABS, DNV, GL), UL 1604 and UL 508 standards. This analogue output cartridge is compatible with Modicon M241C PLC. There is 1 slot for I/O cartridge on TM241C*24 . There are 2 slots for I/O cartridge on TM241C*40.
