Schneider Electric VW3M3302 Lxm I/O Module 1

Schneider Electric VW3M3302 Lxm I/O Module 1

Schneider Electric
SKU:
VW3M3302
|
UPC:
3.60648E+12
Availability:
Contact us to confirm availability and lead times.
$336.96
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
This product is part of the Lexium 32 range, an offer of motion servo drives for machines from 0.15kW to 7kW. The additional I/O module provides 4 discrete inputs, 2 discrete outputs and 2 analogue inputs/outputs. It provides protection from reverse polarity on input. It is furnished with spring terminal for electrical connection. It weighs 0.45kg. This range is compatible with Lexium 32 servo drives. This product is compatible with Lexium 32M. Lexium 32 is a servo drive range with three or four servo drive models and two servo motor families plus an intelligent selection of options. Servo drives and servo motors from 0.15kW to 7kW for maximum performance.
Additional Information
Range Compatibility:
Lexium 32
Accessory / Separate Part Category:
communication accessories
Product Or Component Type:
additionnal I/O module
Accessory / Separate Part Destination:
servo drive
China Rohs Regulation:
X
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Rohs Exemption Information:
Yes
Product Compatibility:
Lexium 32M
Mercury Free:
Yes
Warranty:
18 months
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Net Weight:
0.45 kg
Pvc Free:
Yes
Accessory / Separate Part Type:
module
Reverse Polarity Protection:
yes on input
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Short-Circuit Protection:
yes on output
Circularity Profile:
ENVEOLI1407005EN
Environmental Disclosure:
ENVPEP1407005EN
Electrical Connection:
spring terminal
Protection Type:
reverse polarity protection on input
Input/Output Type:
4 discrete inputs - 3...5 V/15...30 V, 2.5 mA, 0.25 ms || 2 discrete outputs <= 30 V, <= 100 mA, 0.25 ms || 2 analog outputs - 10...10 V, 0...20 mA, , 470 Ohm 12 bits 0.25 ms || 2 analog inputs - 10...10 V, , 20 kOhm 14 bits 0.25 ms
Sustainable Offer Status:
Green Premium product
