Schneider Electric VW3M3501 Safety Module Esm

Schneider Electric VW3M3501 Safety Module Esm

Schneider Electric
SKU:
VW3M3501
|
UPC:
3606480169694
Availability:
Contact us to confirm availability and lead times.
$612.66
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
This product is part of the Lexium 32 range, an offer of motion servo drives for machines from 0.15kW to 7kW. This ESM safety card is for Lexium 32 servo drive. It is an ESM safety card with a rated supply voltage of 24V DC and 19V to 30V voltage limits. It provides reverse polarity protection on input and short-circuit protection on output. It offers safety functions like SOS (safe operating stop), SLS (safe limited speed), SS1 (safe stop 1), STO (safe torque off), SS2 (safe stop 2) with safety levels SIL 3, SILCL 3 and PL = e. It meets EN/IEC 61508, ISO 13849-1 and EN/IEC 62061 standards. This card is compatible with Lexium 32 servo drive. Lexium 32 is a servo drive range with three or four servo drive models and two servo motor families plus an intelligent selection of options. Servo drives and servo motors from 0.15kW to 7kW for maximum performance.
Additional Information
Accessory / Separate Part Category:
communication option
Pvc Free:
Yes
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Safety Level:
SIL 3 IEC 61508 || SILCL 3 IEC 62061 || PL = e ISO 13849-1
China Rohs Regulation:
X
Safety Function:
SOS (safe operating stop) || SLS (safe limited speed) || SS1 (safe stop 1) || STO (safe torque off) || SS2 (safe stop 2)
Voltage State 1 Guaranteed:
>= 15 V
Discrete Output Number:
7
Accessory / Separate Part Type:
eSM safety card
Product Compatibility:
Lexium 32
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Mercury Free:
Yes
Voltage State 0 Guaranteed:
<= 5 V
Range Compatibility:
Lexium 32
[Us] Rated Supply Voltage:
24 V DC 19-30 V
Short-Circuit Protection:
yes on output
Product Or Component Type:
eSM safety card
Discrete Input Number:
11
Circularity Profile:
ENVEOLI1407005EN
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Environmental Disclosure:
ENVPEP1407005EN
Standards:
IEC 61508 || ISO 13849-1 || IEC 62061
Sustainable Offer Status:
Green Premium product
Rohs Exemption Information:
Yes
Accessory / Separate Part Destination:
servo drive
Reverse Polarity Protection:
yes on input
Warranty:
18 months
Datasheet:
View
