Schneider Electric XACA9411 Round Head For Pushbut To N Spring Retur
Schneider Electric
$6.03
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This Harmony XAC, booted head for push buttons operates with spring return / impulse mechanism and uses front mounting. This white booted button head provides a simple solution to comply with hygiene requirement in food, beverage industries as well as healthcare and pharmaceuticals. It is easily combined with Harmony range of contact blocks to perform a large variety of control functions. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP65, making it ideal for operation in harsh environments. The booted head prevents growth of bacteria in joints and gaps: ideal for high hygiene environments like food and beverage industry. Its wide range of operating temperatures from -40°C to 70°C allows versatility in usage of product.
- Marking:
- unmarked
- Product Compatibility:
- XACA..
- Circularity Profile:
- N/A
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Mounting Location:
- front of enclosure
- Range Of Product:
- Harmony XAC
- Ambient Air Temperature For Storage:
- -40-70 °C
- Net Weight:
- 0.01 kg
- Warranty:
- 18 months
- Ik Degree Of Protection:
- IK08 IEC 62262
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr
- Operator Additional Information:
- booted
- Product Or Component Type:
- head for push-button
- Component Name:
- XACA
- Overvoltage Category:
- class II IEC 61140
- Rohs Exemption Information:
- Yes
- Shock Resistance:
- 100 gn IEC 60068-2-27
- Sale Per Indivisible Quantity:
- 10
- Vibration Resistance:
- 15 gn 10-500 Hz)IEC 60068-2-6
- Cap/Operator Or Lens Colour:
- white
- Ip Degree Of Protection:
- IP65 conforming to IEC 60529
- Ambient Air Temperature For Operation:
- -25-70 °C
- China Rohs Regulation:
- X
- Reach Free Of Svhc:
- Yes
- Mercury Free:
- Yes
- Toxic Heavy Metal Free:
- Yes
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Standards:
- CSA C22.2 No 14 || IEC 60947-5-1 || IEC 60204-32 || UL 508
