Schneider Electric XACB9221 Pushbutton Head Pack of 10

(No reviews yet) Write a Review

Write a Review

Schneider Electric XACB9221 Pushbutton Head Pack of 10

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

XACB9221

UPC:

3389110644708

MPN:

Condition:

New

Mercury Free:

Yes

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

China Rohs Regulation:

X

Electrical Shock Protection Class:

class II IEC 61140

Warranty:

18 months

Range Of Product:

Harmony XAC

Standards:

IEC 60947-5-1 || EN 60947-5-1 || CSA C22.2 No 14

Ambient Air Temperature For Operation:

-40-70 °C

Rohs Exemption Information:

Yes

Net Weight:

0.005 kg

Product Or Component Type:

head for push-button

Component Name:

XACB

Sale Per Indivisible Quantity:

10

Shock Resistance:

100 gn IEC 60068-2-27

California Proposition 65:

WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr

Vibration Resistance:

15 gn 10-500 Hz)IEC 60068-2-6

Product Compatibility:

XESD1191 || XESD1181 || XESD1291 || XESD1281

Cap/Operator Or Lens Colour:

white

Reach Free Of Svhc:

Yes

Marking:

unmarked

Reach Regulation:

Free of Substances of Very High Concern above the threshold

Ip Degree Of Protection:

IP65 conforming to IEC 60529

Operating Travel:

16 mm

Ambient Air Temperature For Storage:

-40-70 °C

Toxic Heavy Metal Free:

Yes

Ik Degree Of Protection:

IK08 EN 50102

Operator Additional Information:

booted
