Schneider Electric XACB9221 Pushbutton Head Pack of 10
Schneider Electric
$164.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric XACB9221 Pushbutton Head Pack of 10
Head for push button, Harmony XAC, plastic, white, booted, 16mm
- Mercury Free:
- Yes
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- China Rohs Regulation:
- X
- Electrical Shock Protection Class:
- class II IEC 61140
- Warranty:
- 18 months
- Range Of Product:
- Harmony XAC
- Standards:
- IEC 60947-5-1 || EN 60947-5-1 || CSA C22.2 No 14
- Ambient Air Temperature For Operation:
- -40-70 °C
- Rohs Exemption Information:
- Yes
- Net Weight:
- 0.005 kg
- Product Or Component Type:
- head for push-button
- Component Name:
- XACB
- Sale Per Indivisible Quantity:
- 10
- Shock Resistance:
- 100 gn IEC 60068-2-27
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr
- Vibration Resistance:
- 15 gn 10-500 Hz)IEC 60068-2-6
- Product Compatibility:
- XESD1191 || XESD1181 || XESD1291 || XESD1281
- Cap/Operator Or Lens Colour:
- white
- Reach Free Of Svhc:
- Yes
- Marking:
- unmarked
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Ip Degree Of Protection:
- IP65 conforming to IEC 60529
- Operating Travel:
- 16 mm
- Ambient Air Temperature For Storage:
- -40-70 °C
- Toxic Heavy Metal Free:
- Yes
- Ik Degree Of Protection:
- IK08 EN 50102
- Operator Additional Information:
- booted
- Catalog:
- View
- Datasheet:
- View
