Schneider Electric XAPG39203 Metallicenclosure
Schneider Electric
$142.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This is part of the range Harmony XAP, XB2 SL metal enclosures for Harmony XB4. This Harmony XAPG is a die-cast empty control station. It has 3 cut-outs, 3 vertical openings, diameter 22mm for 3 functions. Designed for industry, it offers operating simplicity, flexibility and robustness. Its protection index is IP65. Its wide range of operating temperatures from -25°C to 70°C allows versatility in usage of product. It provides a zinc alloy grey (RAL 7032) enclosure. Its dimensions are 175mm height, 80mm wide, 51.5mm deep. It is designed for machines builders (automotive, textile, wood) and services and infrastructures, energy distribution, building, airport. It is compatible with the Harmony XB4 range of control and signaling units.
- Cable Entry:
- cable gland || 1 x cable gland
- Circularity Profile:
- N/A
- Mercury Free:
- Yes
- China Rohs Regulation:
- X
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr
- Range Of Product:
- Harmony XAP
- Warranty:
- 18 months
- Material:
- die cast zinc
- Ik Degree Of Protection:
- IK07 IEC 62262
- Sustainable Offer Status:
- Green Premium product
- Product Or Component Type:
- die-cast empty control station
- Number Of Vertical Rows:
- 1
- Reach Free Of Svhc:
- Yes
- Colour Of Base Of Enclosure:
- grey RAL 7032)
- Ip Degree Of Protection:
- IP65 IEC 60529
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Toxic Heavy Metal Free:
- Yes
- Cad Overall Depth:
- 51.5 mm
- Colour Of Cover:
- grey RAL 7032)
- Product Destination:
- for à 22 mm control and signalling units
- Sale Per Indivisible Quantity:
- 1
- Ambient Air Temperature For Operation:
- -25-70 °C
- Ambient Air Temperature For Storage:
- -40-70 °C
- Device Short Name:
- XAPG
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Resistance To Chemical Agents:
- special treatment can be obtained on request
- Net Weight:
- 0.870 kg
- Thread Type:
- 3/4 NPT
- Protective Treatment:
- TH
- Control Station Type:
- metal
- Cad Overall Height:
- 175 mm
- Compatibility Code:
- XAPG
- Number Of Horizontal Rows:
- 3
- Rohs Exemption Information:
- Yes
- Number Of Cut-Out:
- 3 cut-outs
- Environmental Disclosure:
- ENVPEP2111017EN
- Cad Overall Width:
- 80 mm
- Cut-Out Dimensions:
- Ã 22 mm
- Electrical Shock Protection Class:
- class I IEC 60536 || class I NF C 20-030
- Datasheet:
- View
