Schneider Electric XAPG39503 Metallicenclosure
Schneider Electric
$104.37
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
XAPG 22mm enclosures are for industrial applications. These empty enclosures can be used with push buttons and pilot lights from the XB4 metal or XB5 plastic push button ranges. This grey die cast zinc alloy enclosure has openings for three operators. The spacing of the operator holes allows the enclosure vertically and have enough electrical clearance to mount the operators properly. The enclosure is NEMA 4 and 13 rated. Enclosure is 6.89 inches tall, 3.15 inches wide and 3.03 inches deep. The relay weighs 2.52 lbs. Enclosure is UL Listed and CSA certified. "It is suitable for automotive, textiles, timber, energy distribution, public works, building and airport applications." "This product is certified by CSA." "It is compatible with the XB4 range 22mm control and signaling units." "Harmony XAM, XAP industrial IP67 enclosures combines simple installation, configuration flexibility and robust construction." "The Harmony XAM, XAP range of insulated or metal enclosures designed for use in severe environments."
- Resistance To Chemical Agents:
- special treatment can be obtained on request
- Control Station Type:
- metal
- Ambient Air Temperature For Operation:
- -25-70 °C
- Sale Per Indivisible Quantity:
- 1
- Product Destination:
- for à 22 mm control and signalling units
- Protective Treatment:
- TH
- Ambient Air Temperature For Storage:
- -40-70 °C
- Cad Overall Depth:
- 77 mm
- Number Of Cut-Out:
- 3 cut-outs
- Rohs Exemption Information:
- Yes
- Toxic Heavy Metal Free:
- Yes
- Mercury Free:
- Yes
- Colour Of Base Of Enclosure:
- grey RAL 7032)
- Product Or Component Type:
- die-cast empty control station
- Device Short Name:
- XAPG
- Material:
- die cast zinc
- Ik Degree Of Protection:
- IK07 EN/IEC 62262
- Circularity Profile:
- N/A
- Cad Overall Width:
- 80 mm
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr
- Net Weight:
- 1.145 kg
- Sustainable Offer Status:
- Green Premium product
- Number Of Vertical Rows:
- 1
- China Rohs Regulation:
- X
- Environmental Disclosure:
- ENVPEP2111017EN
- Cad Overall Height:
- 175 mm
- Thread Type:
- 3/4 NPT
- Cable Entry:
- cable gland || 1 x cable gland
- Reach Free Of Svhc:
- Yes
- Ip Degree Of Protection:
- IP65 IEC 60529
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Colour Of Cover:
- grey RAL 7032)
- Warranty:
- 18 months
- Range Of Product:
- Harmony XAP
- Electrical Shock Protection Class:
- class I IEC 60536 || class I NF C 20-030
- Number Of Horizontal Rows:
- 3
- Compatibility Code:
- XAPG
- Cut-Out Dimensions:
- Ã 22 mm
