Schneider Electric XB4BV34 Transformer 120 V Pilot L

Schneider Electric XB4BV34 Transformer 120 V Pilot L

Schneider Electric
SKU:
XB4BV34
|
UPC:
3389110887235
Availability:
Contact us to confirm availability and lead times.
$128.70
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
This Harmony XB4 plain lens modular red pilot light is supplied with 110V to 120V AC/DC, uses BA9s base. It has a metal bezel. This pilot light, designed to last without maintenance for a bright indicator of process and machine operations, is easily installed into a standard 22mm diameter cut-outs and connected with simple screw-clamp connections. It is clearly distinguishable visually at a distance thanks to a bright and long lasting BA9s base illumination. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66/IP67/IP69/IP69K, making it ideal for operation in harsh environments.
Additional Information
Sustainable Offer Status:
Green Premium product
Light Block Supply:
via integral transformer 1.2 VA 6 V
Ambient Air Temperature For Operation:
-40-55 °C
Vibration Resistance:
5 gn 12-500 Hz)IEC 60068-2-6
Nema Degree Of Protection:
NEMA 13 || NEMA 4X
Signalling Type:
steady
[Ui] Rated Insulation Voltage:
600 V 3)IEC 60947-1
Ip Degree Of Protection:
IP66 IEC 60529 || IP67 || IP69 || IP69K
Product Certifications:
UL Listed || CSA
Fixing Collar Material:
zamak
Mounting Diameter:
22 mm
Shape Of Signaling Unit Head:
round
Depth:
78 mm
Terminals Description Iso N°1:
(X1-X2)PL
Device Short Name:
XB4
Bulb Base:
BA 9s
Mercury Free:
Yes
Ik Degree Of Protection:
IK06 IEC 50102
Protective Treatment:
TH
Head Type:
standard
Connections - Terminals:
screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60947-1
Product Or Component Type:
pilot light
Warranty:
18 months
Device Presentation:
complete product
Circularity Profile:
ENVEOLI2308026EN
Environmental Disclosure:
ENVPEP2308026EN
Electrical Shock Protection Class:
class I IEC 60536
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Operator Additional Information:
with plain lens
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Ambient Air Temperature For Storage:
-40-70 °C
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Cap/Operator Or Lens Colour:
red
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Height:
47 mm
China Rohs Regulation:
X
[Uimp] Rated Impulse Withstand Voltage:
6 kV IEC 60947-1
Net Weight:
0.152 kg
Standards:
IEC 60947-5-5 || JIS C8201-5-1 || IEC 60947-5-4 || CSA C22.2 No 14 || IEC 60947-5-1 || IEC 60947-1 || UL 508 || JIS C8201-1
Resistance To High Pressure Washer:
7000000 Pa 55 °C 0.1 m
Shock Resistance:
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Light Source:
incandescent
Range Of Product:
Harmony XB4
Sale Per Indivisible Quantity:
1
[Us] Rated Supply Voltage:
110...120 V AC 50/60 Hz
Rohs Exemption Information:
Yes
Width:
30 mm
Bezel Material:
chromium plated metal
