Schneider Electric XB4BW24G5 Metal Push-To-Test Pilot Light 110 120V

(No reviews yet) Write a Review

Write a Review

Schneider Electric XB4BW24G5 Metal Push-To-Test Pilot Light 110 120V

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

XB4BW24G5

UPC:

3606489420642

MPN:

Condition:

New

Embedding Depth:

43 mm

Product Or Component Type:

push-to-test pilot light

Sale Per Indivisible Quantity:

1

Device Short Name:

XB4

Mounting Diameter:

22 mm

Width:

30 mm

Service Life:

1.5 year(s)

[Uimp] Rated Impulse Withstand Voltage:

6 kV IEC 60947-1

Light Source:

universal LED

China Rohs Regulation:

X

Tightening Torque:

0.8-1.2 N.m IEC 60947-1

[Us] Rated Supply Voltage:

110...120 V AC 50/60 Hz

Ambient Air Temperature For Operation:

-40-70 °C

Current Consumption:

14 mA

Mercury Free:

Yes

Depth:

55 mm

Light Source Colour:

red

Important Message:

A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks

Height:

42 mm

Range Of Product:

Harmony XB4

Cap/Operator Or Lens Colour:

red

Shock Resistance:

30 gn 18 ms) half sine wave acceleration IEC 60068-2-6 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-6

Product Certifications:

UL Listed || BV || DNV || GL || CSA || LROS (Lloyds register of shipping)

Surge Withstand:

1 kV

Net Weight:

0.09 kg

Vibration Resistance:

5 gn 12-500 Hz)IEC 60068-2-6

Fixing Collar Material:

metal

Ip Degree Of Protection:

IP66 IEC 60536 || IP67 || IP69 || IP69K

Connections - Terminals:

screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60068-2-27 || screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60068-2-27

Protective Treatment:

TH

[Ui] Rated Insulation Voltage:

600 V 3)IEC 60947-1

Rohs Exemption Information:

Yes

Overvoltage Category:

class II IEC 60536

Resistance To High Pressure Washer:

7000000 Pa 55 °C 0.1 m

Bezel Material:

metal

Ik Degree Of Protection:

IK05 IEC 50102

Nema Degree Of Protection:

NEMA 13 IEC 60529 || NEMA 4X

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Ambient Air Temperature For Storage:

-40-70 °C

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Standards:

CSA C22.2 No 14 || IEC 60947-1 || IEC 60947-5-1 || IEC 60947-5-4 || GB 14048.5 || JIS C8201-5-1 || UL 508 || JIS C8201-1

Signalling Type:

steady

Shape Of Signaling Unit Head:

round

Eu Rohs Directive:

Compliant with Exemptions

Catalog:

View

Datasheet:

View
