Schneider Electric XB5AA731327 Complete Plastic Double Headed Pushbutto

(No reviews yet) Write a Review

Write a Review

Schneider Electric XB5AA731327 Complete Plastic Double Headed Pushbutto

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

XB5AA731327

UPC:

3389119043526

MPN:

Condition:

New

Nema Degree Of Protection:

NEMA 13 || NEMA 4X

Mounting Diameter:

22 mm

Short-Circuit Protection:

10 A cartridge fuse gG IEC 60947-5-1

Operator Profile:

red projecting, STOP white) || green flush, II white)

Sustainable Offer Status:

Green Premium product

Connections - Terminals:

screw clamp terminals, >= 1 x 0.22 mm² without cable end IEC 60947-1 || spring terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || spring terminals, >= 1 x 0.22 mm² without cable end IEC 60947-1

Shape Of Signaling Unit Head:

rectangular

Operators Description:

green ''I'' - green ''II'' - red ''STOP''

Warranty:

18 months

China Rohs Regulation:

X

Contacts Usage:

standard contacts

Mechanical Durability:

1000000 cycles

Range Of Product:

Harmony XB5

Electrical Durability:

1000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 3 A 120 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 4 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, DC-13,

Electrical Shock Protection Class:

class II IEC 61140

Net Weight:

0.063 kg

[Uimp] Rated Impulse Withstand Voltage:

6 kV IEC 60947-1

Type Of Operator:

spring return

Positive Opening:

with IEC 60947-5-1 appendix K

Device Presentation:

complete product

Rohs Exemption Information:

Yes

Ambient Air Temperature For Storage:

-40-70 °C

Ip Degree Of Protection:

IP67 IEC 60529 || IP69 IEC 60529 || IP69K

Tightening Torque:

0.8-1.2 N.m IEC 60947-1

Vibration Resistance:

5 gn 2-500 Hz)IEC 60068-2-6

Product Or Component Type:

triple-headed push-button

Fixing Collar Material:

plastic

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Circularity Profile:

ENVEOLI1710010EN

Shape Of Screw Head:

cross JIS No 1 || cross Philips no 1 || cross pozidriv No 1 || slotted flat Ø 4 mm || slotted flat Ø 5.5 mm

[Ie] Rated Operational Current:

3 A 240 V, AC-15, A600 IEC 60947-5-1 || 6 A 120 V, AC-15, A600 IEC 60947-5-1 || 0.1 A 600 V, DC-13, Q600 IEC 60947-5-1 || 0.27 A 250 V, DC-13, Q600 IEC 60947-5-1 || 0.55 A 125 V, DC-13, Q600 IEC 60947-5-1 || 1.2 A 600 V, AC-15, A600 IEC 60947-5-1

Shock Resistance:

30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27

Ambient Air Temperature For Operation:

-25-70 °C

Contact Operation:

slow-break

Ik Degree Of Protection:

IK05 IEC 50102

Device Short Name:

XB5

Head Type:

standard

Contacts Material:

silver alloy (Ag/Ni)

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Operating Travel:

1.5 mm NC changing electrical state) || 2.6 mm NO changing electrical state) || 4.3 mm total travel)

Operating Force:

3.5 N NC changing electrical state || 3.8 N NO changing electrical state

Product Certifications:

LROS (Lloyds register of shipping) || UL Listed || BV || DNV || GL || CSA

Environmental Disclosure:

ENVPEP1710010EN

[Ith] Conventional Free Air Thermal Current:

10 A IEC 60947-5-1

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Mercury Free:

Yes

Bezel Material:

dark grey plastic

Contacts Type And Composition:

2 NO + 1 NC

[Ui] Rated Insulation Voltage:

600 V 3)IEC 60947-1

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Operator Profile:

2 flush - 1 central projecting STOP push-buttons

Electrical Reliability:

λ < 10exp(-6) 5 V 1 mA in clean environment IEC 60947-5-4 || λ < 10exp(-8) 17 V 5 mA in clean environment IEC 60947-5-4

Colour Of Marking:

white marking when green, red or black caps || black marking when white caps

Standards:

IEC 60947-5-4 || JIS C8201-5-1 || CSA C22.2 No 14 || IEC 60947-5-1 || IEC 60947-1 || UL 508 || JIS C8201-1

Resistance To High Pressure Washer:

7000000 Pa 55 °C 0.1 m
