Schneider Electric XB5AT842 D40 Emergency Stop Pp Head

Schneider Electric XB5AT842 D40 Emergency Stop Pp Head

Schneider Electric
SKU:
XB5AT842
|
UPC:
3606480623684
$79.50
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
This Harmony XB5, emergency stop / shutdown 40mm mushroom head modular red push button operates with a latched push-pull mechanism and uses screw-clamp terminals. This emergency stop / shutdown button, also called EMS (Emergency Machine Stop) and EMO (Emergency Off) is easily installed into a standard 22mm diameter cut-outs and connected with simple screw-clamp connections. It is clearly distinguishable visually at a distance thanks to a clear color and a prominent 40mm mushroom shape. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments. Its plastic bezel makes it ideal for applications requiring good resistance to chemical agents and/or double electrical insulation.
Additional Information
[Ith] Conventional Free Air Thermal Current:
10 A IEC 60947-5-1
Shape Of Screw Head:
cross Philips no 1 || cross pozidriv No 1 || slotted flat Ø 4 mm || slotted flat Ø 5.5 mm
Rohs Exemption Information:
Yes
Head Type:
standard
Device Presentation:
complete product
Height:
43 mm
Width:
40 mm
Standards:
IEC 60947-5-4 || IEC 60364-5-53 || IEC 60204-1 || ISO 13850 || IEC 60947-5-1 || JIS C8201-5-1 || IEC 60947-1 || UL 508 || CSA C22.2 No 14 || IEC 60947-5-5 || JIS C8201-1
Ambient Air Temperature For Storage:
-40-70 °C
Sustainable Offer Status:
Green Premium product
Sale Per Indivisible Quantity:
1
Fixing Collar Material:
plastic
Contacts Usage:
standard contacts
Positive Opening:
with IEC 60947-5-1 appendix K
Tightening Torque:
0.8-1.2 N.m IEC 60947-1
Operating Travel:
1.5 mm NC changing electrical state) || 4.3 mm total travel)
Electrical Reliability:
λ < 10exp(-6) 5 V, 1 mA in clean environment IEC 60947-5-4 || λ < 10exp(-8) 17 V, 5 mA in clean environment IEC 60947-5-4
Resistance To High Pressure Washer:
7000000 Pa 55 °C 0.1 m
Operator Profile:
red mushroom Ø 40 mm, unmarked
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
[Uimp] Rated Impulse Withstand Voltage:
6 kV IEC 60947-1
Bezel Material:
dark grey plastic
Reach Regulation:
Free of Substances of Very High Concern above the threshold
Contact Operation:
slow-break
Protective Treatment:
TH
Product Or Component Type:
emergency stop push-button || emergency switching off push-button
Electrical Durability:
1000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 3 A 120 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 4 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, DC-13,
Contacts Material:
silver alloy (Ag/Ni)
Mechanical Durability:
300000 cycles
Depth:
82 mm
Mounting Diameter:
22 mm
Short-Circuit Protection:
10 A cartridge fuse gG IEC 60947-5-1
[Ie] Rated Operational Current:
3 A 240 V, AC-15, A600 IEC 60947-5-1 || 6 A 120 V, AC-15, A600 IEC 60947-5-1 || 0.1 A 600 V, DC-13, Q600 IEC 60947-5-1 || 0.27 A 250 V, DC-13, Q600 IEC 60947-5-1 || 0.55 A 125 V, DC-13, Q600 IEC 60947-5-1 || 1.2 A 600 V, AC-15, A600 IEC 60947-5-1
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Environmental Disclosure:
ENVPEP1710010EN
Type Of Operator:
trigger action and mechanical latching
Vibration Resistance:
5 gn 2-500 Hz)IEC 60068-2-6
Toxic Heavy Metal Free:
Yes
Circularity Profile:
ENVEOLI1710010EN
Device Short Name:
XB5
Ip Degree Of Protection:
IP66 IEC 60529 || IP67 || IP69 || IP69K
Terminals Description Iso N°1:
(11-12)NC
Ambient Air Temperature For Operation:
-40-70 °C
Reset:
push-pull
Connections - Terminals:
screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, >= 1 x 0.22 mm² without cable end IEC 60947-1
Product Certifications:
CSA || DNV || BV || UL Listed || GL || LROS (Lloyds register of shipping)
Reach Free Of Svhc:
Yes
Mercury Free:
Yes
California Proposition 65:
WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Shock Resistance:
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Net Weight:
0.065 kg
Nema Degree Of Protection:
NEMA 13 || NEMA 4X
China Rohs Regulation:
X
Range Of Product:
Harmony XB5
Overvoltage Category:
class II IEC 60536
[Ui] Rated Insulation Voltage:
600 V 3)IEC 60947-1
Ik Degree Of Protection:
IK03 IEC 50102
Shape Of Signaling Unit Head:
round
Catalog:
View
Datasheet:
View
