Schneider Electric XB5AVG6 Pilot Light, Complete, 110-120V, Blue

(No reviews yet) Write a Review

Write a Review

Schneider Electric XB5AVG6 Pilot Light, Complete, 110-120V, Blue

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

XB5AVG6

UPC:

3389110136920

MPN:

Condition:

New

Bulb Base:

integral LED

Important Message:

A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks

Mounting Diameter:

22 mm

Nema Degree Of Protection:

NEMA 13 || NEMA 4X

Mercury Free:

Yes

Rohs Exemption Information:

Yes

Operator Additional Information:

with plain lens

Terminals Description Iso N°1:

(X1-X2)PL

Range Of Product:

Harmony XB5

Supply Voltage Limits:

100-132 V AC

Sale Per Indivisible Quantity:

1

Circularity Profile:

ENVEOLI1710010EN

Sustainable Offer Status:

Green Premium product

Device Presentation:

complete product

Product Certifications:

CSA || UL Listed

Ik Degree Of Protection:

IK05 IEC 50102

Service Life:

100000 h at rated voltage and 25 °C

Ambient Air Temperature For Operation:

-40-70 °C

Electromagnetic Emission:

class B IEC 55011

Cap/Operator Or Lens Colour:

blue

Net Weight:

0.038 kg

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Product Or Component Type:

pilot light

Warranty:

18 months

Resistance To Fast Transients:

2 kV IEC 61000-4-4

Device Short Name:

XB5

Shape Of Signaling Unit Head:

round

Ip Degree Of Protection:

IP66 IEC 60529 || IP67 IEC 60529 || IP69 IEC 60529 || IP69K ISO 20653

Width:

30 mm

Resistance To Electromagnetic Fields:

10 V/m IEC 61000-4-3

Vibration Resistance:

5 gn 12-500 Hz)IEC 60068-2-6

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Signalling Type:

steady

Resistance To High Pressure Washer:

7000000 Pa 55 °C 0.1 m

Current Consumption:

14 mA

Ambient Air Temperature For Storage:

-40-70 °C

Depth:

54 mm

Bezel Material:

dark grey plastic

Standards:

CSA C22.2 No 14 || IEC 60947-1 || IEC 60947-5-1 || IEC 60947-5-4 || JIS C8201-5-1 || UL 508 || JIS C8201-1

Overvoltage Category:

class II IEC 60536

[Ui] Rated Insulation Voltage:

250 V 3)IEC 60947-1

Gcr Bridge:

XB5AVCUST04

Shock Resistance:

50 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 30 gn 11 ms) half sine wave acceleration IEC 60068-2-27

Resistance To Electrostatic Discharge:

6 kV on contact (on metal parts) IEC 61000-4-2 || 8 kV in free air (in insulating parts) IEC 61000-4-2

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Environmental Disclosure:

ENVPEP1710010EN

Electromagnetic Compatibility:

electrostatic discharge - test level: 6 kV (on contact (on metal parts)) conforming to IEC 61000-4-2 || electrostatic discharge - test level: 8 kV (in free air (in insulating parts)) conforming to IEC 61000-4-2 || electromagnetic emission class B con

Head Type:

standard

Fixing Collar Material:

plastic

Connections - Terminals:

screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60947-1

Surge Withstand:

1 kV IEC 61000-4-5

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

[Us] Rated Supply Voltage:

110...120 V AC 50/60 Hz

China Rohs Regulation:

X

Light Source Colour:

blue

Height:

42 mm

Protective Treatment:

TH

Light Source:

universal LED

Compatibility Code:

XB5

[Uimp] Rated Impulse Withstand Voltage:

4 kV IEC 60947-1
