Schneider Electric XB5AVM5 Pilot Light, Complete, 230-240V, Orange

(No reviews yet) Write a Review

Write a Review

Schneider Electric XB5AVM5 Pilot Light, Complete, 230-240V, Orange

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

XB5AVM5

UPC:

3389110903874

MPN:

Condition:

New

Gcr Bridge:

XB5AVCUST05

Overvoltage Category:

class II IEC 60536

Mercury Free:

Yes

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Light Source:

universal LED

Standards:

CSA C22.2 No 14 || UL 508 || IEC 60947-5-1 || IEC 60947-5-4 || IEC 60947-1 || JIS C8201-5-1 || JIS C8201-1

Ik Degree Of Protection:

IK05 IEC 50102

Resistance To High Pressure Washer:

7000000 Pa 55 °C 0.1 m

Signalling Type:

steady

Resistance To Fast Transients:

2 kV IEC 61000-4-4

Fixing Collar Material:

plastic

Protective Treatment:

TH

Sale Per Indivisible Quantity:

1

Ip Degree Of Protection:

IP66 IEC 60529 || IP67 IEC 60529 || IP69 IEC 60529 || IP69K ISO 20653

Rohs Exemption Information:

Yes

Service Life:

100000 h at rated voltage and 25 °C

Important Message:

A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks

Device Presentation:

complete product

Electromagnetic Emission:

class B IEC 55011

China Rohs Regulation:

X

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Terminals Description Iso N°1:

(X1-X2)PL

Compatibility Code:

XB5

Circularity Profile:

ENVEOLI1710010EN

[Us] Rated Supply Voltage:

230...240 V AC 50/60 Hz

Resistance To Electrostatic Discharge:

6 kV on contact (on metal parts) IEC 61000-4-2 || 8 kV in free air (in insulating parts) IEC 61000-4-2

Ambient Air Temperature For Operation:

-40-70 °C

Warranty:

18 months

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Mounting Diameter:

22 mm

[Uimp] Rated Impulse Withstand Voltage:

4 kV IEC 60947-1

Head Type:

standard

Shape Of Signaling Unit Head:

round

[Ui] Rated Insulation Voltage:

250 V 3)IEC 60947-1

Resistance To Electromagnetic Fields:

10 V/m IEC 61000-4-3

Electromagnetic Compatibility:

electrostatic discharge - test level: 6 kV (on contact (on metal parts)) conforming to IEC 61000-4-2 || electrostatic discharge - test level: 8 kV (in free air (in insulating parts)) conforming to IEC 61000-4-2 || electromagnetic emission class B con

Product Or Component Type:

pilot light

Cap/Operator Or Lens Colour:

orange

Supply Voltage Limits:

195-264 V AC

Ambient Air Temperature For Storage:

-40-70 °C

Bulb Base:

integral LED

Bezel Material:

dark grey plastic

Height:

42 mm

Range Of Product:

Harmony XB5

Nema Degree Of Protection:

NEMA 13 || NEMA 4X

Environmental Disclosure:

ENVPEP1710010EN

Depth:

54 mm

Operator Additional Information:

with plain lens

Shock Resistance:

50 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 30 gn 11 ms) half sine wave acceleration IEC 60068-2-27

Sustainable Offer Status:

Green Premium product

Surge Withstand:

1 kV IEC 61000-4-5

Product Certifications:

CSA || UL Listed

Net Weight:

0.038 kg

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Connections - Terminals:

screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60947-1

Vibration Resistance:

5 gn 12-500 Hz)IEC 60068-2-6

Light Source Colour:

orange

Width:

30 mm

Device Short Name:

XB5

Current Consumption:

14 mA
