Schneider Electric XB5EVB1 Monolithic Led Pilot Light, White, 24V
This Harmony XB5, plain lens monolithic white pilot light is supplied with 24V AC/DC, uses a universal LED and screw clamp terminals. This single component pilot light provides clear visual feedback on the status of your machines. It is easily installed into standard 22mm diameter cut-outs and connected with simple screw-clamp connections. It is clearly distinguishable visually at a distance due to clear colors and illumination via universal LED, enabling complex machine statuses to be read at a glance. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66 / IP67 / IP69 / IP69K, making it ideal for operation in harsh environments. Its plastic bezel makes it ideal for applications requiring good resistance to chemical agents and/or double electrical insulation.
- [Us] Rated Supply Voltage:
- 24 V AC/DC 50/60 Hz
- Circularity Profile:
- ENVEOLI1710010EN
- [Ui] Rated Insulation Voltage:
- 250 V 3)IEC 60947-1
- Ip Degree Of Protection:
- IP66 IEC 60529 || IP67 IEC 60529 || IP69 IEC 60529 || IP69K ISO 20653
- Mercury Free:
- Yes
- Important Message:
- A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks
- Width:
- 29 mm
- Ambient Air Temperature For Operation:
- -25-70 °C
- Sale Per Indivisible Quantity:
- 1
- Electromagnetic Emission:
- class B IEC 55011
- Electromagnetic Compatibility:
- electrostatic discharge - test level: 6 kV (on contact (on metal parts)) conforming to IEC 61000-4-2 || electrostatic discharge - test level: 8 kV (in free air (in insulating parts)) conforming to IEC 61000-4-2 || electromagnetic emission class B con
- Resistance To Fast Transients:
- 2 kV IEC 61000-4-4
- Height:
- 29 mm
- Vibration Resistance:
- 5 gn 12-500 Hz)IEC 60068-2-6
- Product Certifications:
- CSA || UL Listed
- Ik Degree Of Protection:
- IK05 IEC 50102
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Environmental Disclosure:
- ENVPEP1710010EN
- Device Presentation:
- monolithic product
- [Uimp] Rated Impulse Withstand Voltage:
- 4 kV IEC 60947-1
- Shock Resistance:
- 50 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 30 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- Warranty:
- 18 months
- Fixing Collar Material:
- plastic
- Mounting Diameter:
- 22 mm
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- China Rohs Regulation:
- X
- Shape Of Signaling Unit Head:
- round
- Cap/Operator Or Lens Colour:
- white
- Bezel Material:
- dark grey plastic
- Overvoltage Category:
- class II IEC 60536
- Compatibility Code:
- XB5
- Bulb Base:
- integral LED
- Resistance To Electrostatic Discharge:
- 6 kV on contact (on metal parts) IEC 61000-4-2 || 8 kV in free air (in insulating parts) IEC 61000-4-2
- Head Type:
- standard
- Resistance To High Pressure Washer:
- 7000000 Pa 55 °C 0.1 m
- Current Consumption:
- 18 mA
- Light Source Colour:
- white
- Net Weight:
- 0.038 kg
- Standards:
- IEC 60947-1 || IEC 60947-5-4 || JIS C8201-5-1 || CSA C22.2 No 14 || UL 508 || IEC 60947-5-1 || JIS C8201-1
- Resistance To Electromagnetic Fields:
- 10 V/m IEC 61000-4-3
- Range Of Product:
- Harmony XB5
- Surge Withstand:
- 1 kV IEC 61000-4-5
- Device Short Name:
- XB5
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Sustainable Offer Status:
- Green Premium product
- Terminals Description Iso N°1:
- (X1-X2)PL
- Light Source:
- universal LED
- Supply Voltage Limits:
- 19.2-30 V DC || 21.6-26.4 V AC
- Protective Treatment:
- TH
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Depth:
- 54 mm
- Ambient Air Temperature For Storage:
- -40-70 °C
- Connections - Terminals:
- screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60947-1
- Signalling Type:
- steady
- Rohs Exemption Information:
- Yes
- Nema Degree Of Protection:
- NEMA 13 || NEMA 4X
- Product Or Component Type:
- pilot light
- Operator Additional Information:
- with plain lens
- Service Life:
- 100000 h at rated voltage and 25 °C
