Schneider Electric XB5EVM5 Monolithic Led Pilot Light, Orange, 230V

(No reviews yet) Write a Review

Write a Review

Schneider Electric

Schneider Electric XB5EVM5 Monolithic Led Pilot Light, Orange, 230V

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

XB5EVM5

UPC:

3389119041652

MPN:

Condition:

New

Warranty:

18 months

Ambient Air Temperature For Operation:

-25-70 °C

China Rohs Regulation:

X

Resistance To Electrostatic Discharge:

6 kV on contact (on metal parts) IEC 61000-4-2 || 8 kV in free air (in insulating parts) IEC 61000-4-2

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Operator Additional Information:

with plain lens

Ambient Air Temperature For Storage:

-40-70 °C

Overvoltage Category:

class II IEC 60536

Ip Degree Of Protection:

IP66 IEC 60529 || IP67 IEC 60529 || IP69 IEC 60529 || IP69K ISO 20653

Environmental Disclosure:

ENVPEP1710010EN

Standards:

IEC 60947-5-4 || JIS C8201-5-1 || UL 508 || IEC 60947-1 || CSA C22.2 No 14 || IEC 60947-5-1 || JIS C8201-1

Light Source:

universal LED

Mercury Free:

Yes

Device Short Name:

XB5

Electromagnetic Emission:

class B IEC 55011

Shape Of Signaling Unit Head:

round

Depth:

54 mm

Nema Degree Of Protection:

NEMA 13 || NEMA 4X

Connections - Terminals:

screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60947-1

Net Weight:

0.038 kg

Product Certifications:

CSA || UL Listed

Circularity Profile:

ENVEOLI1710010EN

Vibration Resistance:

5 gn 12-500 Hz)IEC 60068-2-6

Shock Resistance:

50 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 30 gn 11 ms) half sine wave acceleration IEC 60068-2-27

Compatibility Code:

XB5

Protective Treatment:

TH

Mounting Diameter:

22 mm

Important Message:

A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks

Sustainable Offer Status:

Green Premium product

Terminals Description Iso N°1:

(X1-X2)PL

Bulb Base:

integral LED

Device Presentation:

monolithic product

Sale Per Indivisible Quantity:

1

Head Type:

standard

[Us] Rated Supply Voltage:

230...240 V AC 50/60 Hz

Ik Degree Of Protection:

IK05 IEC 50102

Current Consumption:

14 mA

Fixing Collar Material:

plastic

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Range Of Product:

Harmony XB5

Rohs Exemption Information:

Yes

Bezel Material:

dark grey plastic

Supply Voltage Limits:

195-264 V AC

Height:

29 mm

Resistance To High Pressure Washer:

7000000 Pa 55 °C 0.1 m

Surge Withstand:

1 kV IEC 61000-4-5

Width:

29 mm

Service Life:

100000 h at rated voltage and 25 °C

[Ui] Rated Insulation Voltage:

250 V 3)IEC 60947-1

Signalling Type:

steady

Cap/Operator Or Lens Colour:

orange

[Uimp] Rated Impulse Withstand Voltage:

4 kV IEC 60947-1

Light Source Colour:

orange

Resistance To Electromagnetic Fields:

10 V/m IEC 61000-4-3

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Resistance To Fast Transients:

2 kV IEC 61000-4-4

Product Or Component Type:

monolithic pilot light

Electromagnetic Compatibility:

electrostatic discharge - test level: 6 kV (on contact (on metal parts)) conforming to IEC 61000-4-2 || electrostatic discharge - test level: 8 kV (in free air (in insulating parts)) conforming to IEC 61000-4-2 || electromagnetic emission class B con

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Datasheet:

View
