Schneider Electric XB5EVM6 Monolithic Led Pilot Light, Blue, 230V

(No reviews yet) Write a Review

Write a Review

Schneider Electric XB5EVM6 Monolithic Led Pilot Light, Blue, 230V

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

XB5EVM6

UPC:

3389119041676

MPN:

Condition:

New

Shock Resistance:

50 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 30 gn 11 ms) half sine wave acceleration IEC 60068-2-27

Sale Per Indivisible Quantity:

1

Range Of Product:

Harmony XB5

Cap/Operator Or Lens Colour:

blue

Depth:

54 mm

Ambient Air Temperature For Operation:

-25-70 °C

Resistance To High Pressure Washer:

7000000 Pa 55 °C 0.1 m

Width:

29 mm

Terminals Description Iso N°1:

(X1-X2)PL

[Uimp] Rated Impulse Withstand Voltage:

4 kV IEC 60947-1

[Us] Rated Supply Voltage:

230...240 V AC 50/60 Hz

Connections - Terminals:

screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60947-1

China Rohs Regulation:

X

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Service Life:

100000 h at rated voltage and 25 °C

Overvoltage Category:

class II IEC 60536

Fixing Collar Material:

plastic

Operator Additional Information:

with plain lens

Bezel Material:

dark grey plastic

Rohs Exemption Information:

Yes

Protective Treatment:

TH

Light Source:

universal LED

Device Short Name:

XB5

Circularity Profile:

ENVEOLI1710010EN

Ik Degree Of Protection:

IK05 IEC 50102

Resistance To Electrostatic Discharge:

6 kV on contact (on metal parts) IEC 61000-4-2 || 8 kV in free air (in insulating parts) IEC 61000-4-2

Shape Of Signaling Unit Head:

round

Electromagnetic Emission:

class B IEC 55011

Light Source Colour:

blue

Product Or Component Type:

monolithic pilot light

Ambient Air Temperature For Storage:

-40-70 °C

Nema Degree Of Protection:

NEMA 13 || NEMA 4X

Current Consumption:

14 mA

Electromagnetic Compatibility:

electrostatic discharge - test level: 6 kV (on contact (on metal parts)) conforming to IEC 61000-4-2 || electrostatic discharge - test level: 8 kV (in free air (in insulating parts)) conforming to IEC 61000-4-2 || electromagnetic emission class B con

Supply Voltage Limits:

195-264 V AC

Important Message:

A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks

Warranty:

18 months

[Ui] Rated Insulation Voltage:

250 V 3)IEC 60947-1

Device Presentation:

monolithic product

Head Type:

standard

Mercury Free:

Yes

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Sustainable Offer Status:

Green Premium product

Compatibility Code:

XB5

Surge Withstand:

1 kV IEC 61000-4-5

Environmental Disclosure:

ENVPEP1710010EN

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Ip Degree Of Protection:

IP66 IEC 60529 || IP67 IEC 60529 || IP69 IEC 60529 || IP69K ISO 20653

Resistance To Fast Transients:

2 kV IEC 61000-4-4

Height:

29 mm

Vibration Resistance:

5 gn 12-500 Hz)IEC 60068-2-6

Bulb Base:

integral LED

Resistance To Electromagnetic Fields:

10 V/m IEC 61000-4-3

Mounting Diameter:

22 mm

Signalling Type:

steady

Product Certifications:

UL Listed || CSA

Net Weight:

0.038 kg

Standards:

CSA C22.2 No 14 || IEC 60947-5-4 || IEC 60947-5-1 || JIS C8201-5-1 || IEC 60947-1 || UL 508 || JIS C8201-1
