Schneider Electric XB6AV1BB Round Pilot Light Diam 16 Ip 65 White In
This Harmony XB6 white, complete pilot light is part of the range diameter 16mm plastic, Harmony XB6 modular. It has a circular head shape and is supplied with an integral LED and faston connection type. Its reduced diameter 16mm makes it suitable to applications where less space is available for mounting, like small machines and control panels. This range comes with good color purity and offers the advantage of LED brightness. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP65.
- Electrical Shock Protection Class:
- class II IEC 61140
- Width:
- 18 mm
- Current Consumption:
- 15 mA
- Ambient Air Temperature For Storage:
- -40-70 °C
- Net Weight:
- 0.015 kg
- [Us] Rated Supply Voltage:
- 12...24 V AC/DC
- Bezel Material:
- plastic
- Standards:
- EN/IEC 60947-1 || EN/IEC 60947-5-5 || CSA C22.2 No 14 || UL 508 || JIS C 852 || EN/IEC 60947-5-1 || JIS C8201-5-1 || JIS C8201-1
- Warranty:
- 18 months
- Ambient Air Temperature For Operation:
- -25-70 °C
- Product Certifications:
- CCC || GOST || CSA || UL
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Environmental Disclosure:
- ENVPEP1710010EN
- Resistance To Electrostatic Discharge:
- 6 kV on contact (on metal parts) IEC 61000-4-2 || 8 kV in free air (in insulating parts) IEC 61000-4-2
- Light Block Supply:
- direct
- Sustainable Offer Status:
- Green Premium product
- Shape Of Signaling Unit Head:
- round
- Protective Treatment:
- TC
- Surge Withstand:
- 1 kV direct contact IEC 61000-4-5 || 2 kV in free air IEC 61000-4-5
- Resistance To Electromagnetic Fields:
- 10 V/m IEC 61000-4-3
- Signalling Type:
- steady
- Circularity Profile:
- ENVEOLI1710010EN
- Mounting Diameter:
- 16 mm
- [Ui] Rated Insulation Voltage:
- 250 V 2)EN/IEC 60947-1
- Nema Degree Of Protection:
- NEMA 13 UL 50 || NEMA 4 UL 50 || NEMA 4X UL 50 || NEMA 13 CSA C22.2 No 94 || NEMA 4 CSA C22.2 No 94 || NEMA 4X CSA C22.2 No 94
- Operating Position:
- any position
- Terminals Description Iso N°1:
- (+ -)PL
- Mercury Free:
- Yes
- Electromagnetic Emission:
- class B EN 55011
- Ip Degree Of Protection:
- IP65 IEC 60529
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Depth:
- 57 mm
- Cap/Operator Or Lens Colour:
- white
- Sale Per Indivisible Quantity:
- 1
- Light Source:
- LED
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Bulb Base:
- integral LED
- Device Short Name:
- XB6
- Product Or Component Type:
- complete pilot light
- [Uimp] Rated Impulse Withstand Voltage:
- 4 kV EN/IEC 60947-1
- Connections - Terminals:
- Faston connectors 2.8 x 0.5 mm
- Range Of Product:
- Harmony XB6
- China Rohs Regulation:
- X
- Supply Voltage Limits:
- 6-30 V AC/DC
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Rohs Exemption Information:
- Yes
- Height:
- 18 mm
- Vibration Resistance:
- +/- 3 mm 2-500 Hz)IEC 60068-2-6 || 5 gn 2-500 Hz)IEC 60068-2-6
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- Resistance To Fast Transients:
- 2 kV IEC 61000-4-4
