Schneider Electric

Schneider Electric XB7EV05GP Pilot Light Led Yellow 120V Ac Pack of 10

(No reviews yet) Write a Review
SKU:
XB7EV05GP
UPC:
3389119022804
Condition:
New
Shape Of Signaling Unit Head:
round
[Uimp] Rated Impulse Withstand Voltage:
6 kV IEC 60947-1
Service Life:
70000 h at rated voltage and 25 °C
Warranty:
18 months
Terminals Description Iso N°1:
(X1-X2)PL
Rohs Exemption Information:
Yes
Connections - Terminals:
screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60947-1
Tightening Torque:
0.8-1.2 N.m IEC 60947-1
Mounting Diameter:
22 mm
Range Of Product:
Harmony XB7
Protective Treatment:
TH
Ip Degree Of Protection:
IP20 IEC 60529 rear face) || IP65 IEC 60529 front face)
Toxic Heavy Metal Free:
Yes
Net Weight:
0.02 kg
Ambient Air Temperature For Storage:
-40-70 °C
Supply Voltage Limits:
100-132 V AC
Reach Free Of Svhc:
Yes
Width:
29 mm
Cap/Operator Or Lens Colour:
yellow
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Product Or Component Type:
pilot light
Depth:
54 mm
Device Presentation:
monolithic product
Signalling Type:
steady
Ambient Air Temperature For Operation:
-25-70 °C
Bulb Base:
integral LED
Height:
29 mm
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
[Ui] Rated Insulation Voltage:
250 V 3)IEC 60947-1
Device Mounting:
fixing hole 22.5 mm 22.3 +0.4/0 IEC 60947-5-1
Reach Regulation:
Free of Substances of Very High Concern above the threshold
Fixing Mode:
fixing nut beneath head 2-2.4 N.m
Current Consumption:
18...21 mA
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Sustainable Offer Status:
Green Premium product
Sale Per Indivisible Quantity:
10
Device Short Name:
XB7
Environmental Disclosure:
ENVPEP1805012EN
Nema Degree Of Protection:
NEMA 4 UL 50 E || NEMA 12 UL 50 E
Mercury Free:
Yes
Vibration Resistance:
5 gn 2-500 Hz)IEC 60068-2-6
Electromagnetic Compatibility:
disturbing field emission class B conforming to IEC 55011
Overvoltage Category:
class II IEC 60536
Shape Of Screw Head:
cross JIS No 1 || cross Philips no 1 || cross pozidriv No 1 || slotted flat Ø 4 mm || slotted flat Ø 5.5 mm
[Us] Rated Supply Voltage:
120 V AC 50/60 Hz
China Rohs Regulation:
X
Standards:
UL 508 || JIS C8201-5-1 || CSA C22.2 No 14 || IEC 60947-1 || IEC 60947-5-1 || JIS C8201-1
Fixing Center:
>= 30 x 40 mm support panel) metal 1-6 mm || >= 30 x 40 mm support panel) plastic 2-6 mm
Shock Resistance:
50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Circularity Profile:
ENVEOLI1805012EN
Light Source:
LED
Brochure:
View
Datasheet:
View
$360.00

Description

This Harmony XB7, plain lens monolithic yellow pilot light is supplied with 120V AC, uses an integral LED and screw clamp terminals. It is easily installed into standard 22mm diameter cut-outs and connected with simple screw-clamp connections. It is clearly distinguishable visually at a distance due to clear colors and illumination via integral LED, enabling complex machine statuses to be read at a glance. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP65, making it ideal for operation in harsh environments. It has a double insulated plastic bezel. Its wide range of operating temperatures from -25°C to 70°C allows versatility in usage of product.
