Schneider Electric

Schneider Electric XB7EV75P Reducer Yellow Pilot Ligh T Pack of 100

(No reviews yet) Write a Review

Write a Review

Schneider Electric

Schneider Electric XB7EV75P Reducer Yellow Pilot Ligh T Pack of 100

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

XB7EV75P

UPC:

3389110839661

MPN:

Condition:

New

Warranty:

18 months

Electromagnetic Compatibility:

disturbing field emission class B conforming to IEC 55011

Net Weight:

0.02 kg

Vibration Resistance:

5 gn 2-500 Hz)IEC 60068-2-6

Terminals Description Iso N°1:

(X1-X2)PL

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Shape Of Screw Head:

cross JIS No 1 || cross Philips no 1 || cross pozidriv No 1 || slotted flat Ø 4 mm || slotted flat Ø 5.5 mm

Protective Treatment:

TH

Shock Resistance:

50 gn 11 ms) half sine wave acceleration IEC 60068-2-27

Ambient Air Temperature For Operation:

-25-55 °C

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Depth:

54 mm

Signalling Type:

steady

[Us] Rated Supply Voltage:

230 V AC 50/60 Hz

Height:

29 mm

Bulb Base:

BA 9s

Ambient Air Temperature For Storage:

-40-70 °C

Range Of Product:

Harmony XB7

Mounting Diameter:

22 mm

Circularity Profile:

ENVEOLI1805012EN

Device Mounting:

fixing hole 22.5 mm 22.3 +0.4/0 IEC 60947-5-1

Rohs Exemption Information:

Yes

Sustainable Offer Status:

Green Premium product

Device Short Name:

XB7

Tightening Torque:

0.8-1.2 N.m IEC 60947-1

Standards:

JIS C8201-5-1 || IEC 60947-1 || CSA C22.2 No 14 || IEC 60947-5-1 || UL 508 || JIS C8201-1

Ip Degree Of Protection:

IP20 IEC 60529 rear face) || IP54 IEC 60529 front face)

[Uimp] Rated Impulse Withstand Voltage:

6 kV IEC 60947-1

Overvoltage Category:

class II IEC 60536

China Rohs Regulation:

X

Shape Of Signaling Unit Head:

round

Connections - Terminals:

Faston connectors 6.35 x 0.8 mm IEC 60947-1 || forked type tag connectors 6.5 mm IEC 60947-1 || screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60947-1

[Ui] Rated Insulation Voltage:

250 V 3)IEC 60947-1

Width:

29 mm

Compatibility Code:

XB7

Toxic Heavy Metal Free:

Yes

Light Source:

incandescent

Fixing Center:

>= 30 x 40 mm support panel) metal 1-6 mm || >= 30 x 40 mm support panel) plastic 2-6 mm

Light Block Supply:

direct through resistor <2.6 W 130 V

Device Presentation:

monolithic product

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Environmental Disclosure:

ENVPEP1805012EN

Nema Degree Of Protection:

NEMA 12

Service Life:

2000 h at rated voltage and 25 °C

Mercury Free:

Yes

Reach Free Of Svhc:

Yes

Operator Additional Information:

with plain lens

Cap/Operator Or Lens Colour:

yellow

Reach Regulation:

Free of Substances of Very High Concern above the threshold

Product Or Component Type:

pilot light

Fixing Mode:

fixing nut beneath head 2-2.4 N.m

Sale Per Indivisible Quantity:

10

Supply Voltage Limits:

195-264 V AC
