Schneider Electric XB7NA3133 Pb - Spring Rtn, Green -1No - White [Sta Pack of 10
This Harmony XB7, monolithic green push button marked with a "START" lettering operates with a spring return / impulse mechanism and screw clamp terminals. It is easily installed into standard 22mm diameter panel cut-outs and connected to control circuits with classic screw-clamp connections. Its schematic is clearly distinguishable thanks to clear colors and markings, minimizing errors during initial wiring and later maintenance operations. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP65, making it ideal for operation in harsh environments. It has a double insulated plastic bezel. Its wide range of operating temperatures from -25°C to 70°C allows versatility in usage of product.
- Standards:
- CSA C22.2 No 14 || JIS C8201-5-1 || IEC 60947-1 || IEC 60947-5-1 || UL 508 || JIS C8201-1
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Device Short Name:
- XB7
- [Ui] Rated Insulation Voltage:
- 250 V 3)IEC 60947-1
- Protective Treatment:
- TH
- Cad Overall Height:
- 29 mm
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Cad Overall Width:
- 29 mm
- Circularity Profile:
- ENVEOLI1805012EN
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Range Of Product:
- Harmony XB7
- Ip Degree Of Protection:
- IP20 IEC 60529 rear face) || IP65 IEC 60529 front face)
- Mechanical Durability:
- 1000000 cycles
- Shape Of Screw Head:
- cross JIS No 1 || cross Philips no 1 || cross pozidriv No 1 || slotted flat à 4 mm || slotted flat à 5.5 mm
- Rohs Exemption Information:
- Yes
- Overvoltage Category:
- class II IEC 61140
- Type Of Operator:
- spring return
- Ambient Air Temperature For Storage:
- -40-70 °C
- Fixing Mode:
- fixing nut beneath head 2-2.4 N.m
- Mercury Free:
- Yes
- Shock Resistance:
- 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27 || 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27
- Warranty:
- 18 months
- Ambient Air Temperature For Operation:
- -25-70 °C
- Sustainable Offer Status:
- Green Premium product
- [Ie] Rated Operational Current:
- 0.1 A 250 V, DC-13, R300 IEC 60947-5-1 || 0.22 A 125 V, DC-13, R300 IEC 60947-5-1 || 0.3 A 240 V, AC-14, D300 IEC 60947-5-1 || 0.6 A 120 V, AC-14, D300 IEC 60947-5-1
- [Uimp] Rated Impulse Withstand Voltage:
- 4 kV IEC 60947-1
- Toxic Heavy Metal Free:
- Yes
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Operator Profile:
- green flush, START white)
- China Rohs Regulation:
- X
- Product Certifications:
- GOST || CCC
- Sale Per Indivisible Quantity:
- 10
- Vibration Resistance:
- 5 gn 2-500 Hz)IEC 60068-2-6
- Terminals Description Iso N°1:
- (13-14)NO
- Contacts Type And Composition:
- 1 NO
- Positive Opening:
- with (only NO)
- Product Or Component Type:
- push-button
- Device Presentation:
- monolithic product
- Net Weight:
- 0.021 kg
- Cad Overall Depth:
- 51.5 mm
- Device Mounting:
- fixing hole 22.5 mm 22.3 +0.4/0 IEC 60947-1
- Electrical Reliability:
- λ <= 10exp(-6) 17 V, 5 mA IEC 60947-5-4
- Mounting Diameter:
- 22 mm
- Environmental Disclosure:
- ENVPEP1805012EN
- Short-Circuit Protection:
- 4 A cartridge fuse gG IEC 60947-5-1
- Tightening Torque:
- 0.8-1.2 N.m IEC 60947-1
- Shape Of Signaling Unit Head:
- round
- Fixing Center:
- >= 30 x 40 mm support panel) metal 1-6 mm || >= 30 x 40 mm support panel) plastic 2-6 mm
- Nema Degree Of Protection:
- NEMA 12 UL 50 E || NEMA 3 UL 50 E
- Contact Operation:
- slow-break
- Electrical Durability:
- 1000000 cycles, DC-13, 0.3 A 24 V 216000 cyc/mn 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 0.03 A 230 V 216000 cyc/mn 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 0.09 A 240 V 108000 cyc/mn 0.5 IEC 60947-5-1 appendix C
- Connections - Terminals:
- screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, 1 x 0.34...2 x 2.5 mm² without cable end IEC 60947-1
