Schneider Electric XENC1151 Spring Return Contact Block 1 Nc And 1 N
This Harmony XENC1151 is a spring return contact block 1 NC + 1 NO front mounting, 30 or 40mm centres. It is part of the range Harmony XAC pendant control stations for diameter 22mm plastic signaling units. It is designed for single speed applications.
- Rated Operational Power In W:
- 42 W DC-13 1000000 cycles 60 cyc/mn 120 V 0.5 inductive IEC 60947-5-1 appendix C || 45 W DC-13 1000000 cycles 60 cyc/mn 48 V 0.5 inductive IEC 60947-5-1 appendix C || 60 W DC-13 1000000 cycles 60 cyc/mn 24 V 0.5 inductive IEC 60947-5-1 appendix C
- Maximum Resistance Across Terminals:
- 25 MOhm
- China Rohs Regulation:
- X
- Type Of Operator:
- spring return
- Product Or Component Type:
- contact block
- [Ithe] Conventional Enclosed Thermal Current:
- 0.416666666666667
- Contacts Type And Composition:
- 1 NC + 1 NO
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr
- Toxic Heavy Metal Free:
- Yes
- Contact Block Application:
- single speed
- Short-Circuit Protection:
- 10 A fuse protection cartridge gG
- Mechanical Durability:
- 1000000 cycles
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Range Of Product:
- Harmony XAC
- Mounting Of Block:
- front mounting
- Contact Operation:
- slow-break
- Standards:
- IEC 60947-5-1 || CSA C22.2 No 14 || EN 60947-5-1
- Net Weight:
- 0.02 kg
- Electrical Circuit Type:
- control circuit
- Rohs Exemption Information:
- Yes
- Component Name:
- XENC
- [Ui] Rated Insulation Voltage:
- 500 V 3)IEC 60947-1
- Contact Code Designation:
- A300 AC-15, Ue = 240 V, Ie = 3 A IEC 60947-5-1 appendix A || Q300 DC-13, Ue = 250 V, Ie = 0.27 A IEC 60947-5-1 appendix A
- [Uimp] Rated Impulse Withstand Voltage:
- 6 kV IEC 60947-1
- Connections - Terminals:
- screw clamp terminals, 1 x 2.5 mm² with or without cable end || screw clamp terminals, 2 x 1.5 mm² with or without cable end
- Mechanical Interlocking:
- without mechanical interlock
- Ambient Air Temperature For Operation:
- -25-70 °C
- Ambient Air Temperature For Storage:
- -40-70 °C
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Shock Resistance:
- 100 gn IEC 60068-2-27
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Mercury Free:
- Yes
- Terminal Identifier:
- (11-12)NC || (13-14)NO
- Product Compatibility:
- XACB || XACM
- Vibration Resistance:
- 15 gn 10-500 Hz)IEC 60068-2-6
- Contact Block Type:
- single
- Reach Free Of Svhc:
- Yes
- Rated Operational Power In Va:
- 140 VA AC-15 1000000 cycles 60 cyc/mn 24 V 50/60 Hz 0.5 inductive || 385 VA AC-15 1000000 cycles 60 cyc/mn 48 V 50/60 Hz 0.5 inductive || 455 VA AC-15 1000000 cycles 60 cyc/mn 230 V 50/60 Hz 0.5 inductive || 525 VA AC-15 1000000 cycles 60 cyc/mn 127
- Warranty:
- 18 months
- Terminals Description Iso N°1:
- (11-12)NC || (23-24)NO
