Schneider Electric XVC4B3K Indicating Banks 40Mm Led Base Mount 24

Schneider Electric XVC4B3K Indicating Banks 40Mm Led Base Mount 24

Schneider Electric
SKU:
XVC4B3K
|
UPC:
3606480032448
$189.00
(No reviews yet) Write a Review
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
This monolithic tower light is part of the range of pre-assembled and pre-cabled tower lights Harmony type XVC diameter 40mm. It is supplied pre-assembled and pre-cabled with 3 illuminated signaling units (red, orange, green) and and a base fitted with 3 screws for direct mounting on an horizontal surface (IP 54). Supply voltage is 24 V AC/DC. It is designed for long distance indication of the operating states of a machine, visually by means of illuminated signaling units visible through 360° (super bright LED for steady light only). It is used mainly in the food-processing and medical sectors.
Additional Information
Ambient Air Temperature For Storage:
-35-70 °C
Marking:
CE
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Mounting Location:
on base
Material:
polycarbonate: illuminated unit || ABS (acrylonitrile butadiene-styrene): base unit || PBT + ABS (UL94HB): top cover
Beacon Or Indicator Bank Unit Type:
3 illuminated units
Net Weight:
0.14 kg
Overvoltage Category:
class II IEC 61140
Environmental Disclosure:
ENVPEP1904008EN
Height:
170.5 mm
Sound Signalling:
without
Awg Gauge:
AWG 22
Cable Length:
500 mm
China Rohs Regulation:
X
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Protective Treatment:
TC
Light Source:
LED steady red || LED steady or flashing orange || LED steady or flashing green
Rohs Exemption Information:
Yes
Electrical Shock Protection Class:
class II IEC 61140
Product Or Component Type:
complete pre-wired monolithic tower light
Ambient Air Temperature For Operation:
-10-50 °C
Flashing Frequency:
1 Hz
Mercury Free:
Yes
Warranty:
18 months
Ip Degree Of Protection:
IP54 flat surface installation IEC 60529
[Uimp] Rated Impulse Withstand Voltage:
0.8 kV
Circularity Profile:
ENVEOLI1904008EN
Range Of Product:
Harmony XVC4
Cable Cross Section:
0.33-0.33 mm²
Product Certifications:
UL
Device Short Name:
XVC
[Us] Rated Supply Voltage:
24 V
Standards:
IEC 61000-6-2 || IEC 61000-6-3
Product Mounting:
on base
Mounting Diameter:
40 mm
Supply Circuit Type:
AC/DC
Component Name:
XVC
Current Consumption:
75 mA
