Schneider Electric XVC6B15SK Indicating Banks 60Mm Led Base Mount 24
This monolithic tower light is part of the range of pre-assembled and pre-cabled tower lights Harmony type XVC diameter 60mm. It is supplied pre-assembled and pre-cabled with 1 red illuminated signaling unit and a base for mounting on horizontal surface. It also features a buzzer with continuous or intermittent tone and adjustable sound level from 70db to 85db at 1 m, + flashing light. It is designed for long distance indication of the operating states of a machine, visually by means of illuminated signaling units visible through 360°. It features LED for steady or flashing light source, and it can be supplied with 24 V AC/DC. Its protection index is IP54. It provides PC (polycarbonate) illuminated unit, ABS base unit and PBT + ABS (UL94HB) top cover. It weighs 200g and it is 121mm high. It is used mainly in the semi-conductor factories, on conveyor belts and on small food or drink dispensing machines in the commercial sector. It is CE and UL certified. It is designed to be mounted on horizontal surface thanks to its base fitted with 3 screws.
- Ambient Air Temperature For Operation:
- -10-50 °C
- Current Consumption:
- 65 mA
- Flashing Frequency:
- 1 Hz
- Standards:
- EN/IEC 61000-6-2 || EN/IEC 61000-6-4 || EN/IEC 61000-6-3
- [Us] Rated Supply Voltage:
- 24 V
- Component Name:
- XVC
- Protective Treatment:
- TC
- Awg Gauge:
- AWG 22
- Warranty:
- 18 months
- Range Of Product:
- Harmony XVC6
- Product Certifications:
- UL
- Environmental Disclosure:
- ENVPEP1904008EN
- Electrical Shock Protection Class:
- class II EN/IEC 61140
- Light Source:
- LED steady or flashing red
- Cable Cross Section:
- 0.33-0.33 mm²
- Product Or Component Type:
- complete pre-wired monolithic tower light
- Sound Signalling:
- buzzer
- Supply Circuit Type:
- AC/DC
- Cable Length:
- 850 mm
- Beacon Or Indicator Bank Unit Type:
- 1 illuminated unit
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Rohs Exemption Information:
- Yes
- [Uimp] Rated Impulse Withstand Voltage:
- 0.8 kV
- Product Mounting:
- on base
- Ip Degree Of Protection:
- IP54 flat surface installation EN/IEC 60529
- Material:
- polycarbonate: illuminated unit || ABS (acrylonitrile butadiene-styrene): base unit || PBT + ABS (UL94HB): top cover
- China Rohs Regulation:
- X
- Mercury Free:
- Yes
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Circularity Profile:
- ENVEOLI1904008EN
- Ambient Air Temperature For Storage:
- -35-70 °C
- Mounting Diameter:
- 60 mm
- Net Weight:
- 0.2 kg
- Noise Level:
- 70-85 dB continuous or intermittent tone)1 m
- Marking:
- CE
- Height:
- 120.8 mm
- Fundamental Frequency:
- 2.23 kHz
