Schneider Electric

Schneider Electric XVR12B06 Rotating Mirror Beacon Led 120 Mm 24 V B

SKU:

XVR12B06

UPC:

3606480033186

MPN:

Condition:

New

Protective Treatment:

TC

Cad Overall Depth:

120 mm

Material:

ABS (acrylonitrile butadiene-styrene): body part || AS: globe

Electrical Shock Protection Class:

class II IEC 61140

Product Or Component Type:

prewired rotating mirror beacon

China Rohs Regulation:

X

Ambient Air Temperature For Operation:

-10-50 °C

Sustainable Offer Status:

Green Premium product

Current Consumption:

125 mA

Warranty:

18 months

Cable Length:

400 mm

Clamping Connection Capacity:

0.83 mm²

[Uimp] Rated Impulse Withstand Voltage:

0.8 kV

Environmental Disclosure:

ENVPEP1402018EN

Standards:

IEC 61000-6-2 || IEC 61000-6-4

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Mounting Diameter:

120 mm

Ip Degree Of Protection:

IP23 IEC 60529

Rohs Exemption Information:

Yes

Net Weight:

0.5 kg

Product Mounting:

by 3 M5 screws

Circularity Profile:

ENVEOLI1402018EN

Range Of Product:

Harmony XVR

Cad Overall Width:

120 mm

Sound Signalling:

without

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

[Us] Rated Supply Voltage:

24 V AC/DC

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Flashing Frequency:

2.3 Hz

Light Source:

high luminosity LED, blue

Supply Voltage Limits:

19-30 V DC || 21.6-26.4 V AC

Device Short Name:

XVR

Marking:

CE

Ambient Air Temperature For Storage:

-35-70 °C

Awg Gauge:

AWG 18

Brochure:

View

Catalog:

View

Datasheet:

View
