Schneider Electric ZB4BA4TQ Pushbutton Operator Head Pack of 100
Schneider Electric
$1,300.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric ZB4BA4TQ Pushbutton Operator Head Pack of 100
Head for illuminated push button, Harmony XB4, metal, red flush, 22mm, spring return, unmarked, set of 100
- Circularity Profile:
- ENVEOLI1808008EN
- Ambient Air Temperature For Storage:
- -40-70 °C
- Shape Of Signaling Unit Head:
- round
- Nema Degree Of Protection:
- NEMA 13 || NEMA 4X
- Environmental Disclosure:
- ENVPEP1808008EN
- Electrical Composition Code:
- C1 9 single front mounting || C2 9 single and double front mounting || C11 3 single front mounting || C15 1 single front mounting
- Ik Degree Of Protection:
- IK06 IEC 50102
- Type Of Operator:
- spring return
- Product Certifications:
- DNV || BV || GL || UL Listed || LROS (Lloyds register of shipping) || CSA
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Operator Profile:
- red flush, unmarked
- Sale Per Indivisible Quantity:
- 100
- Standards:
- UL 508 || EN/IEC 60947-5-5 || EN/IEC 60947-5-4 || JIS C8201-5-1 || CSA C22.2 No 14 || EN/IEC 60947-5-1 || EN/IEC 60947-1 || JIS C8201-1
- Reach Free Of Svhc:
- Yes
- Vibration Resistance:
- 5 gn 2-500 Hz)IEC 60068-2-6
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Warranty:
- 18 months
- Product Or Component Type:
- head for non-illuminated push-button
- Range Of Product:
- Harmony XB4
- Device Short Name:
- ZB4
- Ip Degree Of Protection:
- IP66 IEC 60529 || IP67 || IP69 || IP69K
- Mercury Free:
- Yes
- Cad Overall Width:
- 29 mm
- Overvoltage Category:
- class I IEC 60536
- Toxic Heavy Metal Free:
- Yes
- Rohs Exemption Information:
- Yes
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- Sustainable Offer Status:
- Green Premium product
- Protective Treatment:
- TH
- Mechanical Durability:
- 10000000 cycles
- Ambient Air Temperature For Operation:
- -40-70 °C
- Cad Overall Depth:
- 28 mm
- Cad Overall Height:
- 29 mm
- Head Type:
- standard
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- China Rohs Regulation:
- X
- Bezel Material:
- chromium plated metal
- Mounting Diameter:
- 22 mm
