Schneider Electric ZB5AA0 Pushbutton Operator Head
This Harmony XB5, flush button head without cap operates with a spring return / impulse mechanism. This button head without cap allows users to customize it with any compatible desired cap to support your machines and operating functions. It is easily installed and replaced on compatible complete push-button units and contact blocks via snap-fit assembly. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66. It has a plastic bezel, this makes it ideal for applications requiring good resistance to chemical agents and/or double electrical insulation. It is designed to fit in a standard 22mm cutout, ensuring compatibility when installing in pre-existing machinery. Its wide range of operating temperatures from -40°C to 70°C allows versatility in usage of product.
- Ik Degree Of Protection:
- IK03 IEC 50102
- Cad Overall Width:
- 29 mm
- Device Short Name:
- ZB5
- Range Of Product:
- Harmony XB5
- Ip Degree Of Protection:
- IP66 IEC 60529 || IP67 || IP69 || IP69K
- Net Weight:
- 0.022 kg
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Type Of Operator:
- spring return
- Cad Overall Height:
- 29 mm
- Mechanical Durability:
- 10000000 cycles
- Operator Profile:
- without cap
- Product Certifications:
- DNV || CSA || BV || LROS (Lloyds register of shipping) || GL || UL Listed
- Ambient Air Temperature For Storage:
- -40-70 °C
- Sustainable Offer Status:
- Green Premium product
- Sale Per Indivisible Quantity:
- 1
- Standards:
- IEC 60947-5-4 || UL 508 || JIS C8201-5-1 || IEC 60947-1 || IEC 60947-5-1 || CSA C22.2 No 14 || JIS C8201-1
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Head Type:
- standard
- Warranty:
- 18 months
- Cad Overall Depth:
- 28 mm
- Shape Of Signaling Unit Head:
- round
- Ambient Air Temperature For Operation:
- -40-70 °C
- Resistance To High Pressure Washer:
- 7000000 Pa 55 °C 0.1 m
- Vibration Resistance:
- 5 gn 2-500 Hz)IEC 60068-2-6
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- Overvoltage Category:
- class II IEC 60536
- Rohs Exemption Information:
- Yes
- Electrical Composition Code:
- C1 9 single front mounting || C2 9 single and double front mounting || C11 3 single front mounting || C15 1 single front mounting || SF1 3 single front mounting || SR1 3 single rear mounting
- Product Or Component Type:
- head for non-illuminated push-button
- Station Name:
- XALD 1...5 cut-outs || XALK 2...5 cut-outs
- Reach Free Of Svhc:
- Yes
- Toxic Heavy Metal Free:
- Yes
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Mercury Free:
- Yes
- Circularity Profile:
- ENVEOLI1710010EN
- Protective Treatment:
- TH
- Mounting Diameter:
- 22 mm
- Bezel Material:
- dark grey plastic
- Nema Degree Of Protection:
- NEMA 13 || NEMA 4X
- China Rohs Regulation:
- X
- Environmental Disclosure:
- ENVPEP1710010EN
