Schneider Electric ZB5AD2TQ Selector Operating Head Pack of 100
Schneider Electric
$2,400.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric ZB5AD2TQ Selector Operating Head Pack of 100
Head for selector switch, Harmony XB5, black handle, 22mm, 2 positions, stay put, set of 10
- Nema Degree Of Protection:
- NEMA 13 || NEMA 4X
- Product Certifications:
- UL Listed || BV || LROS (Lloyds register of shipping) || CSA || GL || DNV
- Mechanical Durability:
- 1000000 cycles
- Mounting Diameter:
- 22 mm
- Environmental Disclosure:
- ENVPEP1710010EN
- Station Name:
- XALD 1...5 cut-outs
- Rohs Exemption Information:
- Yes
- Protective Treatment:
- TH
- Device Short Name:
- ZB5
- Ip Degree Of Protection:
- IP67 IEC 60529 || IP69 IEC 60529 || IP69K
- Mercury Free:
- Yes
- Range Of Product:
- Harmony XB5
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Reach Free Of Svhc:
- Yes
- China Rohs Regulation:
- X
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- Product Or Component Type:
- head for selector switch
- Circularity Profile:
- ENVEOLI1710010EN
- Bezel Material:
- dark grey plastic
- Operator Profile:
- black standard handle
- Shape Of Signaling Unit Head:
- round
- Vibration Resistance:
- 5 gn 2-500 Hz)IEC 60068-2-6
- Cad Overall Height:
- 29 mm
- Operator Position Information:
- 2 positions 90°
- Warranty:
- 18 months
- Sale Per Indivisible Quantity:
- 10
- Ambient Air Temperature For Storage:
- -40-70 °C
- Head Type:
- standard
- Ambient Air Temperature For Operation:
- -40-70 °C
- Toxic Heavy Metal Free:
- Yes
- Electrical Composition Code:
- C3 6 single front mounting || C4 6 single and double front mounting || C5 5 single front mounting || C6 5 single and double front mounting || C7 4 single front mounting || C8 4 single and double front mounting || C11 3 single front mounting || C15 1
- Overvoltage Category:
- class II IEC 60536
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Resistance To High Pressure Washer:
- 7000000 Pa 55 °C 0.1 m
- Standards:
- IEC 60947-1 || UL 508 || JIS C8201-5-1 || CSA C22.2 No 14 || IEC 60947-5-4 || IEC 60947-5-1 || JIS C8201-1
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Cad Overall Width:
- 29 mm
- Cad Overall Depth:
- 46 mm
- Type Of Operator:
- stay put
- Sustainable Offer Status:
- Green Premium product
- Ik Degree Of Protection:
- IK06 IEC 50102
- Datasheet:
- View
