Schneider Electric ZB5AH06 Push / Push To Release He
Schneider Electric
$26.40
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This blue flush button head provides an ergonomic interface for controlling your machines. It is easily installed and replaced on compatible complete push button units and contact blocks via snap-fit assembly. It is clearly distinguishable visually at a distance thanks to clear color. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66. It makes it ideal for operation in harsh environments.
- Nema Degree Of Protection:
- NEMA 13 || NEMA 4X
- Mechanical Durability:
- 2000000 cycles
- Ambient Air Temperature For Operation:
- -40-70 °C
- Cad Overall Height:
- 29 mm
- Circularity Profile:
- ENVEOLI1710010EN
- Warranty:
- 18 months
- Bezel Material:
- dark grey plastic
- Product Or Component Type:
- head for non-illuminated push-button
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr
- Product Certifications:
- BV || CSA || DNV || LROS (Lloyds register of shipping) || UL Listed || GL
- Device Short Name:
- ZB5
- Ik Degree Of Protection:
- IK03 IEC 50102
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- China Rohs Regulation:
- X
- Ip Degree Of Protection:
- IP66 IEC 60529 || IP67 || IP69 || IP69K
- Protective Treatment:
- TH
- Net Weight:
- 0.018 kg
- Overvoltage Category:
- class II IEC 60536
- Rohs Exemption Information:
- Yes
- Environmental Disclosure:
- ENVPEP1710010EN
- Device Presentation:
- basic element
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Shape Of Signaling Unit Head:
- round
- Head Type:
- standard
- Cad Overall Width:
- 29 mm
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- Electrical Composition Code:
- C11 3 single front mounting || C15 1 single front mounting || SF1 3 single front mounting || SR1 3 single rear mounting || C9 3 single front mounting
- Ambient Air Temperature For Storage:
- -40-70 °C
- Station Name:
- XALD 1...5 cut-outs || XALK 2...5 cut-outs
- Mounting Diameter:
- 22 mm
- Cad Overall Depth:
- 28 mm
- Sale Per Indivisible Quantity:
- 1
- Vibration Resistance:
- 5 gn 2-500 Hz)IEC 60068-2-6
- Mercury Free:
- Yes
- Sustainable Offer Status:
- Green Premium product
- Operator Profile:
- blue flush, unmarked
- Range Of Product:
- Harmony XB5
- Resistance To High Pressure Washer:
- 7000000 Pa 55 °C 0.1 m
- Type Of Operator:
- push-push
