Schneider Electric ZB5AH083C0 Zb5 Yellow Illum. Led Push Push But. Flu

Schneider Electric ZB5AH083C0 Zb5 Yellow Illum. Led Push Push But. Flu

Schneider Electric
SKU:
ZB5AH083C0
|
UPC:
3606489766801
$32.67
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
This illuminated button head for universal LED provides a versatile interface for controlling your machines. It is easily installed/replaced on compatible complete push-button units and contact blocks via snap-fit assembly. It is clearly distinguishable visually at a distance thanks to illum. clear color and by touch due to flush element, minimizing errors in machine control. It is imapct, dust, water and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments.
Additional Information
Product Certifications:
UL Listed || DNV || GL || CSA || BV || LROS (Lloyds register of shipping)
Type Of Operator:
push-push
Cad Overall Width:
29 mm
Ip Degree Of Protection:
IP66 IEC 60529 || IP67
Important Message:
A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks
Reach Regulation:
Free of Substances of Very High Concern above the threshold
Electrical Shock Protection Class:
class II IEC 60536
Resistance To High Pressure Washer:
7000000 Pa 55 °C 0.1 m
Protective Treatment:
TH
Station Name:
XALD 1...5 cut-outs || XALK 2...5 cut-outs
Cad Overall Height:
29 mm
Mounting Diameter:
22 mm
Sale Per Indivisible Quantity:
1
Range Of Product:
Harmony XB5
Ambient Air Temperature For Storage:
-40-70 °C
Toxic Heavy Metal Free:
Yes
Product Compatibility:
universal LED
Ambient Air Temperature For Operation:
-40-70 °C
Shock Resistance:
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Cad Overall Depth:
30 mm
Rohs Exemption Information:
Yes
Product Or Component Type:
head for illuminated push-button
Operator Profile:
yellow flush, unmarked
Shape Of Signaling Unit Head:
round
Mechanical Durability:
500000 cycles
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
China Rohs Regulation:
X
Standards:
EN/IEC 60947-5-4 || CSA C22.2 No 14 || EN/IEC 60947-1 || EN/IEC 60947-5-1 || EN/IEC 60947-5-5 || JIS C8201-5-1 || UL 508 || JIS C8201-1
Reach Free Of Svhc:
Yes
Net Weight:
0.017 kg
Nema Degree Of Protection:
NEMA 13 || NEMA 4X
Vibration Resistance:
5 gn 2-500 Hz)IEC 60068-2-6
Device Presentation:
basic element
Mercury Free:
Yes
Device Short Name:
ZB5
Bezel Material:
plastic colour plated grey
California Proposition 65:
WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Ik Degree Of Protection:
IK05 IEC 50102
Electrical Composition Code:
M5 2 single front mounting integral LED || M6 2 single front mounting integral LED and transformer || M10 2 single front mounting integral LED || MF1 2 single front mounting integral LED || MR1 2 single rear mounting integral LED
Datasheet:
View
